Overview

GPX Vision Kit - 20-90 Minute Vision Kit

Steel vision lite kits for 20-90 minute door applications. Available primed for field paint or with high performance paint by PPG.

Most economical fire and safety rated glazing meeting all the standards for 90 minute temperature rise doors.
Non-wired clear glazing providing the highest visual clarity.
Impact safety rated to meet federal and code standards.
Vision lite kits available in these sizes: 5×35, 6×27, 7×22, and 12×12
Can be used for interior and exterior applications.
Lifetime warranty.
USA manufactured for fast delivery and competitive pricing.

Specifications


SuperLite X-90 Vision Kit - 12" X 12"	SuperLite X-90 Vision Kit - 5" X 35"	SuperLite X-90 Vision Kit - 6" X 27"	SuperLite X-90 Vision Kit - 7" X 22"

Specifications

Material:	Construction:	Fasteners:	Finishes:	Stock Sizes:
20 gauge CRS Frame.	1-1/4" trim with radius corners, mitered and welded. Continuous glass retainer, countersunk mounting holes in the bevel on non-corridor side.	#8 x 7/8" flathead phillips SMS.	Available in bronze or primed finish. Other finishes are available upon request.	5" x 35", 6" x 27", 7" x 22" and 12" x 12".
