Overview


SuperLite® I - 20 Minute Fire Protective Glazing

Product Advantages

  • Most economical fire and safety rated glazing available.
  • Provides superior optical clarity over ceramics.
  • Meets the highest human impact safety requirements.
  • Can be used for interior and exterior applications.
  • Available in specialty architectural make-ups and patterns.
  • Lifetime warranty.
  • USA manufactured for fast lead times and competitive pricing.

Product Specifications

Thickness

¼ in. (6 mm) standard
½ in. (12 mm) custom

Weight

3 lbs. / sq. ft. (15 kg/m²)

Fire Rating

20 minutes without hose stream

Sound Transmission Rating

STC 28

Solar Heat Gain Coefficient

0.82 SHGC

Impact Safety Rating

CPSC 16 CFR 1201 Cat. I and II

Application

Doors, Sidelites, Transoms, Windows/Openings

Listings and Standards

SuperLite® I is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.

Listings

  • Intertek: 20636; 26726; 24569
  • UL: KCMZ.R14212; KCMZ7.R14212
  • CSFM: 4075-1660:0100
  • HPD: 28446

Standards

  • UL 9, UL 10B, UL 10C
  • NFPA 80, NFPA 252, NFPA 257
  • ASTM E152, ASTM E163, ASTM E2074, ASTM E2010-01
  • CPSC 16 CFR 1201 Cat. II
  • ANSI Z97.1

Framing Options

GPX® Architectural Series Fire Protective

GPX® Vision Kit

GPX® Builders Series Fire Protective


See More


Specifications

MAXIMUM SIZES
Fire RatingApplicationMax. CV AreaMax. CV WidthMax. CV HeightStops
20 MinutesSteel Door3,341 in.²
(2.16 m²)		35-1/8 in.
(0.89 m)		95-1/8 in.
(2.42 m)		5/8 in.
(16 mm)
20 MinutesWood Door3,299 in.²
(2.13 m²)		36-1/8 in.
(0.91 m)		91-5/16 in.
(2.32 m)		5/8 in.
(16 mm)
20 MinutesAluminum Door3,436 in.²
(2.22 m²)		36-3/4 in.
(0.93 m)		95-1/2 in.
(2.43 m)		5/8 in.
(16 mm)
20 MinutesSteel, Wood and Aluminum
Sidelites*, Transoms*		5,760 in.²
(3.72 m²)		96 in.
(2.44 m)		95-1/2 in.
(2.43 m)		5/8 in.
(16 mm)
20 MinutesSteel Window/Openings*5,760 in.²
(3.72 m²)		96 in.
(2.44 m)		95-1/2 in.
(2.43 m)		5/8 in.
(16 mm)
*Requires AHJ approval for these applications because it is tested without hose stream.
