SAFTI FIRST -GPX® EZ Frame Fire Rated Walls

DOWNLOADS

45-120 Minute Fire Rated Sidelites, Transoms, Windows/Openings
60-120 Minute Fire Rated Walls


Category: fire rated borrowed lights | fire rated door frames | fire rated glazed assemblies...

MasterFormat: Aluminum Doors and Frames | Aluminum Frames | Special Function Glazing...


View Product Details From Manufacturer


SAFTI FIRST
100 N Hill Drive
Suite 12
Brisbane, CA 94005
Tel: (888) 653-3333
Fax: (415) 824-5900

info@safti.com

https://safti.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


GPX® EZ Frame Fire Rated Walls

Product Advantages

  • Flexible, economical and creative solution for fire protective windows/openings or fire resistive walls without visible metal framing.
  • Fire protective or fire resistive performance depending on glazing choice.
  • Can be used with SuperLite® II-XL 45, SuperLite® II-XL 60, SuperLite® II-XL 120, SuperLite® II-XLB 60, SuperLite® II-XLB 120, SuperClear® 45-HS (hose stream) or SuperClear® 45-HS-LI (hose stream-low iron).
  • Standard 5 year limited warranty.
  • USA manufactured for fast lead times and competitive pricing.

Product Specifications

Fire Rating

45-120 minutes with hose stream

Listings and Standards

GPX® EZ Frame is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.

Listings

  • Intertek: 24569; 51170; 48350
  • UL: U536; U541; U550; W477

Standards

With SuperClear® 45-HS or SuperClear® 45-HS-LI

  • UL 9
  • NFPA 257
  • CAN-ULC S106

With SuperLite® II-XL or SuperLite® II-XLB

  • ASTM E119
  • UL 263
  • CAN-ULC S101

Glazing Options

SuperClear® 45-HS

SuperClear® 45-HS-LI

SuperLite® II-XLB 120

SuperLite® II-XLB 60

SuperLite® II-XL 120

SuperLite® II-XL 60

SuperLite® II-XL 45


See More


Specifications

MAXIMUM SIZES
Fire RatingGlazingApplicationMax. CV AreaMax. CV WidthMax. CV Height
45 MinutesSuperClear® 45-HS
SuperClear® 45-HS-LI		Sidelites, Transoms,
Windows/Openings		3,880 in.²
(2.50 m²)		96 in.
(2.44 m)		96 in.
(2.44 m)
45 MinutesSuperLite® II-XL 45Sidelites, Transoms,
Windows/Openings		4,952 in.²
(3.19 m²)		124 in.
(3.15 m)		124 in.
(3.15 m)
60 MinutesSuperLite® II-XL 60Walls4,952 in.²
(3.19 m²)		124 in.
(3.15 m)		124 in.
(3.15 m)
60 MinutesSuperLite® II-XLB 60Walls10,000 in.²
(6.45 m²)		125 in.
(3.18 m)		125 in.
(3.18 m)
120 MinutesSuperLite® II-XL 120Walls4,876 in.²
(3.15 m²)		124 in.
(3.15 m)		124 in.
(3.15 m)
120 MinutesSuperLite® II-XLB 120Walls7,980 in.²
(5.15 m²)		133 in.
(3.38 m)		133 in.
(3.38 m)
