GPX® Architectural Series Fire Protective Doors
Product Advantages
- 20-45 minute fire protective aluminum framing for doors, sidelites, transoms and openings.
- Tested to UL 9 / NFPA 257 and UL 10B / UL 10C / NFPA 252.
- 20 minute doors glazed with SuperLite® I-20 minute glazing.
- 45 minute sidelites, transoms and openings glazed with SuperClear® 45-HS (hose stream), SuperClear® 45-HS-LI (hose stream, low-iron) or SuperLite® II-XL 45. Other fire protective glazing can be used upon request.
- SuperLite® II-XL 45 in GPX® Architectural Series Fire Resistive framing can be used in W-30 applications in the IBC because the assembly meets ASTM E119 / UL 263.
- It is available in standard and custom finishes including high performance paint by PPG, clear anodized, bronze anodized, black anodized, Decoral®, wood veneer, ornamental metal and more.
- Approved NFRC CMA glazing component. SAFTI FIRST® has an in-house NFRC ACE Individual to assist designers with project-specific simulations or NFRC Bid Reports.
- Doors delivered factory glazed and prepped for hardware for easy installation.
- Frames delivered K-D standard. Pre-assembly available upon request.
- Can be used for interior and exterior applications.
- Standard 5 year limited warranty.
- USA manufactured for fast lead times and competitive pricing.
Product Specifications
Frame Weight
12 lbs. / sq. ft. (59 kg/m²) for 45 minute sidelites, transoms and windows/openings
Fire Rating
20 minute fire protective doors
45 minute fire protective sidelites, transoms and windows/openings with hose stream
Frame Profile
2-1/2 in. (64 mm) equal sightlines
Finish
Standard and custom high performance paint by PPG, clear anodized, bronze anodized, black anodized, Decoral®, and more
Application
Doors, Sidelites, Transoms, Windows/Openings
Door Profile
5 in. (127 mm) stile
5-1/2 in. (139.7 mm) top rail
1-3/4 in. (44.45 mm) depth
Bottom Rail
10 in. (254 mm) ADA compliant*
*Bottom rail can be modified with AHJ approval
Listings and Standards
GPX® Architectural Series Fire Protective is listed and labeled by Intertek, nationally recognized testing laboratories approved by OSHA.
Listings
- Intertek: 29689; 48962
- HPD: 28599
- Declare: SFT-0001
Standards
- UL 9, UL 10B, UL 10C
- NFPA 80, NFPA 252, NFPA 257
- CAN/ULC S104, CAN/ULC S106
45 minute openings can meet ASTM E119 / UL 263 / CAN/ULC S101 when glazed with SuperLite® II-XL 45 (for W-30 applications in the IBC or when fire resistive performance is desired).
Glazing Options
SuperClear® 45-HS
SuperClear® 45-HS-LI
SuperLite® I-XL
SuperLite® I-XL IGU
SuperLite® II-XL 45
SuperLite® I
