SuperLite® II-XLB 60 - 60 Minute Fire Resistive Glazing

Product Advantages

• Largest tested and approved clear view area of 10,000 in.² (6.45 m²) of any fire resistive glazing product up to 1 hour.
• Tint-free, optically clear fire resistive glazing meeting ASTM E119, ANSI/UL 263 and CAN/ULC S101 with hose stream.
• Butt-glazed option available.
• Can be easily combined with GPX® Architectural Series Fire Resistive framing for a complete and code compliant fire resistive assembly.
• Meets CPSC Cat. II impact safety, the federal maximum safety standard.
• High STC ratings.
• Approved glazing component in the NFRC CMAST database.
• UL and Intertek listed and labeled.
• Standard 5 year limited warranty.
• USA manufactured for fast lead times and competitive pricing.

Product Specifications

Thickness

1-7/8 in. (47.6 mm)

Weight

17.65 lbs. / sq. ft. (86.17 kg/m²)

Fire Rating

60 minutes with hose stream

Impact Safety Rating

CPSC 16 CFR 1201 Cat. I and II

Glass Make-up

Fire resistive tempered glazing with intumescent interlayers

Visible Light Transmittance

0.750 with clear standard
0.861 with clear low-iron

Application

Walls

Sound Rating

STC 44/OITC 40

Listings and Standards

SuperLite® II-XLB 60 is listed and labeled by Underwriters Laboratories, a nationally recognized testing laboratory approved by OSHA.

Listings

• Intertek: 58084
• UL: U560; W477
• HPD: 29036

Standards

• ASTM E119
• ANSI/UL 263, ANSI Z97.1
• CAN/ULC S101
• CPSC 16 CFR 1201 Cat. II

Framing Options

GPX® Architectural Series Fire Resistive

GPX® EZ Frame

GPX® Blast System

GPX® Ballistic Series

GPX® Hurricane

GPX® Curtain Wall
