SAFTI FIRST -GPX® Blast System Fire Resistive Walls

45-120 Minute Fire Resistive and Blast Rated Walls

Category: fire rated borrowed lights | fire rated door frames | fire rated glazed assemblies...

MasterFormat: Aluminum Doors and Frames | Aluminum Frames | Fire-Resistant Glazing...

SAFTI FIRST
100 N Hill Drive
Suite 12
Brisbane, CA 94005
Tel: (888) 653-3333
Fax: (415) 824-5900

Overview

GPX® Blast System Fire Resistive Walls

Product Advantages

45-120 minute clear, fire resistive, GPX® Blast System rated, aluminum clad framing system for walls and windows/openings.
Meets ASTM E119 / UL 263 / NFPA 251 with hose stream up to 2 hours for fire resistance.
Meets a 3-second design loading of 50 psf per UFC 4-010-01 2007 Department of Defense (DOD) Minimum Antiterrorism Standards for Buildings for Blast Resistance.
Meets ASTM E1300 Standard Practice for Determining Load Resistance of Glass in Building
Designed in accordance with ASTM F2248 Standard Practice for Specifying an Equivalent 3-Second Duration Design Loading for Blast Resistant Glazing Fabricated with Laminated Glass.
Can be engineered to meet all levels of blast protection depending on the project, with static and dynamic analysis using Wingard software, which is standard industry practice and allowable under DOD standards.
Comprised of SuperLite® II-XL with one tempered & laminated lite with a minimum interlayer of .030 in. The laminated side is towards the interior of the building to protect the occupants from glass fragments caused by the blast.
Offered in standard and custom finishes including high performance fluoropolymer finishes by PPG, clear anodized, bronze anodized, black anodized, Decoral®, wood veneer, ornamental metal, and more.
5 year manufacturer’s warranty.
USA manufactured for fast lead times and competitive pricing.

Product Specifications

Thickness

Depends on project requirements.
Please contact SAFTI FIRST® for more information.

Weight

Depends on project requirements.
Please contact SAFTI FIRST® for more information.

Fire Rating

45-120 minutes with hose stream

Frame Profile

3 in. (76.2 mm)

Listings and Standards

Standards

Glazing Options

SuperLite® II-XL 120

SuperLite® II-XL 90

SuperLite® II-XL 60

SuperLite® II-XL 45

Specifications

MAXIMUM SIZES

Fire Rating	Glazing	Application	Max. CV Area	Max. CV Width	Max. CV Height	Stops
45 Minutes	SuperLite® II-XL 45	Walls	4,952 in.² (3.19 m²)	124 in. (3.15 m)	124 in. (3.15 m)	1 in. (25 mm)
60 Minutes	SuperLite® II-XL 60	Walls	4,952 in.² (3.19 m²)	124 in. (3.15 m)	124 in. (3.15 m)	1 in. (25 mm)
90 Minutes	SuperLite® II-XL 90	Walls	4,876 in.² (3.15 m²)	124 in. (3.15 m)	124 in. (3.15 m)	1 in. (25 mm)
120 Minutes	SuperLite® II-XL 120	Walls	4,876 in.² (3.15 m²)	124 in. (3.15 m)	124 in. (3.15 m)	1 in. (25 mm)
