SuperClear® 45-HS-LI - 45 Minute Fire Protective Glazing

Product Advantages

• The clearest, most economical fire and safety rated glazing meeting all requirements for 45 minute doors, sidelites, transoms and windows/openings in large sizes.
• Meets the required hose stream test.
• Meets the CPSC Cat. II impact safety test without the need of films or laminates.
• Non-wired and tint-free clear glazing using low-iron glass providing the highest visual clarity.
• Insulated, obscure, decorative or filmed make-ups available.
• Can be used in interior and exterior applications.
• Approved NFRC CMA glazing component. SAFTI FIRST® has an in-house NFRC ACE Individual to assist designers with project-specific simulations or NFRC Bid Reports.
• US Pat. No. 11,479,504 with additional patents pending.
• 2019 Glass Magazine's Product of the Year
• 2019 USGlass Magazine Readers' Choice Award
• Lifetime warranty.
• USA manufactured for fast lead times and competitive pricing.

Product Specifications

Thickness

3/4 in. (19 mm)

Weight

9 lbs. / sq. ft. (44 kg/m²)

Fire Rating

45 minutes with hose stream

Sound Transmission Rating

STC 37

Impact Safety Rating

CPSC 16 CFR 1201 Cat. I and II,
ANSI Z97.1 Class A and B,
CAN/CGSB 12.1 Class A and B

Visible Light Transmittance

83%

Application

Doors, Sidelites, Transoms, Windows/Openings

Outdoor-Indoor Transmission Class

OITC 35

Listings and Standards

SuperClear® 45-HS-LI is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.

Listings

• Intertek: 48346; 48350; 48962
• UL: KCMZ.R14212; KCMZ7.R14212
• CSFM: 4075-1660:0500
• LARR: 26174
• HPD: 28449
• Declare: SFT-0003

Standards

• UL 9, UL 10B, UL 10C
• NFPA 80, NFPA 252, NFPA 257
• CAN/ULC S104, CAN/ULC S106
• CPSC 16 CFR 1201 Cat. I & II
• ANSI Z97.1
• CAN/CGSB 21.1

Framing Options

GPX® Architectural Series Fire Protective

GPX® Vision Kit

GPX® Builders Series Fire Protective

GPX® EZ Frame
