SuperLite® II-XL 120 - 120 Minute Fire Resistive Glazing
Product Advantages
- Maximum fire and impact safety with hose stream and full radiant heat protection.
- Largest tested and approved sizes up to 4,876 in.² (3.15 m²) in standard 1-3/4 in. (45 mm) profile.
- Tint-free and optically clear. Perfect for property lines requirements.
- Available with Starphire Ultra-Clear® glass by Vitro.
- Approved NFRC CMA glazing component. SAFTI FIRST® has an in-house NFRC ACE Individual to assist designers with project-specific simulations or NFRC Bid Reports.
- Available in custom architectural make-ups, such as laminated glass and energy-saving insulated units with NFRC certifications when used with GPX® Architectural Series Fire Resistive framing.
- Can be customized to protect against forced entry, bullets, blast, hurricane and more.
- Standard 5 year limited warranty.
- USA manufactured for fast lead times and competitive pricing.
Product Specifications
Thickness
1-3/4 in. (45 mm) standard
2-3/8 in. (61 mm) when insulated with clear Low-E
Weight
16 lbs. / sq. ft. (79 kg/m²)
Fire Rating
120 minutes with hose stream
Impact Safety Rating
CPSC 16 CFR 1201 Cat. I and II, ANSI Z97.1
Sound Rating in GPX Framing
STC 44 standard profile
STC 44 when insulated with 1/4 in. Low-E
Visible Light Transmittance
0.77 with clear standard
0.878 with clear low-iron
Application
Walls
Hard Body Impact Classification
ASTM C1629/C1629M Level 3
Soft Body Impact Classification
ASTM E695 Level 3
Surface Abrasion Resistance
ASTM D4977 Level 3
Outdoor-Indoor Transmission Class
OITC 40 standard profile
OITC 37 insulated with 1/4 in. Low-E
Listings and Standards
Listings and Standards
SuperLite® II-XL 120 is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.
Listings
- Intertek: 32841; 56534; 51170
- UL: U536
- CSFM: 1080:1660:0104
- LARR: 25786
- HPD: 29036
Standards
- UL 10B, UL 10C, UL 263
- NFPA 80, NFPA 251, NFPA 252, NFPA 257
- ASTM E119, ASTM E152, ASTM E163, ASTM E2074, ASTM E2010-01, ASTM C1629/C1629M, ASTM E695, ASTM D4977
- CPSC 16 CFR 1201 Cat. II
- ANSI Z97.1
- CAN/ULC S101, CAN/ULC S104, CAN/ULC S106
- NFRC 100, NFRC 200, NFRC 500
Framing Options
GPX® Architectural Series Fire Resistive
GPX® EZ Frame
GPX® Blast System
GPX® Ballistic Series
GPX® Hurricane
GPX® Curtain Wall
