GPX® Curtain Wall 60-120 Minute Fire Resistive
Product Advantages
- GPX® Curtain Wall Series is a 60-120 minute fire resistive framing system for multi-story spans of glass.
- It is fully vetted for exterior performance with static & dynamic water pressure testing, air infiltration testing, thermal cycling & condensation evaluation, and structural, seismic, and interstory displacement testing.
- Ideal for property line and wildfire/urban interface situations.
- Provides the clean appearance of conventional aluminum framing with uniform sightlines.
- It is available in standard and custom finishes including high performance paint by PPG, clear anodized, bronze anodized, black anodized, Decoral®, wood veneer, ornamental metal and more.
- Standard 5 year limited warranty.
- USA manufactured for fast lead times and competitive pricing.
Product Specifications
Fire Rating
60-120 minutes with hose stream
Frame Profile
3 in. (76 mm) standard
2-½ in. (63.5 mm) custom
Equal sightlines
Finish
High performance paint by PPG, clear anodized, bronze anodized, black anodized, Decoral®, wood veneer, ornamental metal, and more
Application
Walls
Static Pressure
ASTM E 331-00 at 20.0 psf
Results: No Leakage
Thermal Cycling and Condensation Evaluation
Exterior 170°F: -10°F
Interior 68°F
Results: No Damage
Structural Performance
ASTM E 330 between -75.0 psf to 60.0 psf
Results: No Damage
Seismic Movement test
¾ in. cycled movement horizontally
Results: No Damage
Air Infiltration
ASTM E 283-04 at 6.24 psf.
Results: No Leakage
Dynamic Pressure Water Resistance
AAMA 501-1.05 at 12.0 psf.
Results: No Leakage
Condensation Resistance Factor
68 for frames
71 for glass
Interstory Vertical Displacement Test
1 in. parallel
1 in. perpendicular
Results: No Damage
Listings and Standards
GPX® Curtain Wall Series is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.
Listings
- Intertek: 27695
- HPD: 28599
- Declare: SFT-0001
Standards
- UL 9, UL 10B, UL 10C, UL 263, UL 752-2005
- NFPA 80, NFPA 251, NFPA 252, NFPA 257
- ASTM E119, ASTM E152, ASTM E163, ASTM E2074, ASTM 2010-01
- CPSC 16 CFR 1201 Cat. II
- ANSI Z97.1
- CAN/ULC S101, CAN/ULC S104, CAN/ULC S106
Glazing Options
SuperLite® II-XLM 120
SuperLite® II-XLM 60
SuperLite® II-XLB 120
SuperLite® II-XLB 60
SuperLite® II-XL 120
SuperLite® II-XL 60
