GPX® Builders Series Temperature Rise Doors
Product Advantages
- 60-90 minute full-vision, temperature rise doors with a maximum door height of 10 feet (the largest in the industry. Glazed with SuperLite® II-XL 60, SuperLite® II-XL 90 and SuperLite® II-XL IGU clear fire resistive glazing.
- Easily integrates with GPX® Architectural Series Fire Resistive wall system for a complete 1-2 hour fire resistive wall and door assembly.
- Standard door profile includes 6 in. rail and 2 in. frame. Narrow door profile includes 3-3/4 in. rail and 1-1/8 in. frame. Both include 10 in. ADA compliant bottom rail (can be modified with AHJ approval).
- Can be used in interior and exterior applications.
- Available with high performance fluoropolymer finishes by PPG, or other custom finishes including stainless steel clad or aluminum clad.
- Eligible to meet UL 1784 for smoke and draft control assemblies when used with a Category H gasket. .
- Listed and labeled by UL and Intertek.
- Standard 5 year limited warranty.
- USA manufactured for fast lead times and competitive pricing.
Product Specifications
Fire Rating
60-90 minute temperature rise doors
Meets 450° F temperature rise criteria for 30 minutes
Application
Doors
Finishes
High performance paint by PPG, or other custom finishes including stainless steel clad or aluminum clad
Door Profile
6 in. rail and 2 in. standard frame
3-3/4 in. rail and 1-1/8 in. narrow frame
Door Depth
4 in. minimum
Door Thickness
2-1/2 in. - 3 in.
Bottom Rail
10 in. (254 mm) ADA compliant*
Bottom rail can be modified with AHJ approval
Listings and Standards
GPX® Builders Series Temperature Rise is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.
Listings
- Intertek: 42263; 27833
- HPD: 28600
- Declare: SFT-0002
Standards
- UL 10B, UL 10C
- NFPA 80, NFPA 252
- CAN/ULC S104
- CPSC 16 CFR 1201 Cat. II.
- ANSI Z97.1
Glazing Options
SuperLite® II-XL 90
SuperLite® II-XL 60
