SuperLite® II-XL 60 - 60 Minute Fire Resistive Glazing

Product Advantages

• Maximum fire and impact safety with hose stream and full radiant heat protection.
• Largest tested and approved sizes up to 4,952 in.² (3.19 m²) for door applications in standard 1-3/8 in. (35 mm) profile.
• Fully tested, approved and listed for temperature-rise doors, windows/openings and wall applications.
• Tint-free and optically clear. Perfect for property line requirements.
• Available with Starphire Ultra-Clear® glass by Vitro.
• Approved NFRC CMA glazing component. SAFTI FIRST® has an in-house NFRC ACE Individual to assist designers with project-specific simulations or NFRC Bid Reports.
• Available in any custom architectural make-up, such as laminated glass and energy-saving insulated units with NFRC certifications when used with GPX® Architectural Series Fire Resistive framing.
• Can be customized to protect against forced entry, bullets, blast, hurricane, sound and more.
• Standard 5 year limited warranty.
• USA manufactured for fast lead times and competitive pricing.

Product Specifications

Thickness

1-3/8 in. (35 mm) standard
2-1/8 in. (54 mm) when insulated with clear Low-E

Weight

14 lbs. / sq. ft. (69 kg/m²)

Fire Rating

60 minutes with hose stream

Impact Safety Rating

CPSC 16 CFR 1201 Cat. I and II, ANSI Z97.1

Sound Rating in GPX Framing

STC 43 standard profile
STC 43 when insulated with 1/4 in. Low-E

Visible Light Transmittance

0.786 with clear standard
0.877 with clear low-iron

Hard Body Impact Classification

ASTM C1629/C1629M Level 3

Soft Body Impact Classification

ASTM E695 Level 3

Surface Abrasion Resistance

ASTM D4977 Level 3

Outdoor-Indoor Transmission Class

OITC 39 standard profile
OITC 37 when insulated with 1/4 in. Low-E

Listings and Standards

SuperLite® II-XL 60 is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.

Listings

• Intertek: 32841; 56534; 29689; 29495; 51170
• UL: KCMZ.R14212; KCMZ7.R14212; U518; U536; U541
• CSFM: 4075-1660:0120; 1080-1660:0106
• LARR: 25786
• HPD: 29036


Standards

• UL 9, UL 10B, UL 10C, UL 263
• NFPA 80, NFPA 251, NFPA 252, NFPA 257
• ASTM E119, ASTM E152, ASTM E163, ASTM E2074, ASTM E2010-01, ASTM C1629/C1629M, ASTM E695, ASTM D4977
• CPSC 16 CFR 1201 Cat. II
• ANSI Z97.1
• CAN/ULC S101, CAN/ULC S104, CAN/ULC S106
• NFRC 100, NFRC 200, NFRC 500

Framing Options

GPX® Architectural Series Fire Resistive

GPX® Builders Series Temperature Rise

GPX® EZ Frame

GPX® Blast System

GPX® Ballistic Series

GPX® Hurricane

GPX® Curtain Wall
