SAFTI FIRST -SuperLite® I-XL - 20-45 Minute Fire Protective Glazing

DOWNLOADS

20-45 Minute Fire Protective Glazing
Directional without Hose Stream


Category: 088100 | door glass | security glass...

MasterFormat: Door Louvers and Vision Lights | Fire-Rated Glass and Glazing Systems | Fire-Resistant Glazing...


View Product Details From Manufacturer


SAFTI FIRST
100 N Hill Drive
Suite 12
Brisbane, CA 94005
Tel: (888) 653-3333
Fax: (415) 824-5900

info@safti.com

https://safti.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


SuperLite® I-XL - 20-45 Minute Fire Protective Glazing

Product Advantages

  • Patented directional specialty tempered glazing tested without hose stream that provides partial radiant heat protection not available with ceramics.
  • Accepted by the GSA and AHJs across the country as an economical and value added alternative to traditional unsafe wired glass and expensive ceramics.
  • Meets the highest human impact safety requirements.
  • Approved for 20 minute applications without limitations.
  • Received a General Approval from the City and County of Los Angeles (RR25655). .
  • Regularly specified for use in urban-wildfire exterior applications and perfect for property line requirements.
  • Available in specialty architectural make-ups.
  • Lifetime warranty.
  • USA manufactured for fast lead times and competitive pricing.

Product Specifications

Thickness

1/4 in. (6 mm)

Weight

3 lbs. / sq. ft. (15 kg/m²)

Fire Rating

20-45 minutes without hose stream

Sound Transmission Rating

STC 28

Solar Heat Gain Coefficient

0.70 SHGC

Impact Safety Rating

CPSC 16 CFR 1201 Cat. I and II

Application

Doors, Sidelites, Transoms, Windows/Openings

Listings and Standards

SuperLite® I-XL is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.

Listings

  • Intertek: 23753; 24569
  • CSFM: 4075-1660:0103
  • LARR: 25655
  • HPD: 28447

Standards

  • UL 9, UL 10B, UL 10C
  • NFPA 80, NFPA 252, NFPA 257
  • ASTM E152, ASTM E163, ASTM E2074, ASTM E2010-01
  • CPSC 16 CFR 1201 Cat. II.
  • ANSI Z97.1

Framing Options

GPX® Architectural Series Fire Protective

SAFTI FENCE

GPX® Vision Kit

GPX® Builders Series Fire Protective


See More


Specifications

MAXIMUM SIZES
Fire RatingApplicationMax. CV AreaMax. CV WidthMax. CV HeightStops
20 MinutesWood or Steel Doors3,341 in.²
(2.16 m²)		35-1/8 in.
(0.89 m)		95-1/8 in.
(2.42 m)		5/8 in.
(16 mm)
20 MinutesSteel Sidelites, Transoms
and Windows/Openings		5,760 in.²
(3.72 m²)		96 in.
(2.44 m)		96 in.
(2.44 m)		5/8 in.
(16 mm)
45 Minutes*Wood or Steel Doors3,341 in.²
(2.16 m²)		35-1/8 in.
(0.89 m)		95-1/8 in.
(2.42 m)		5/8 in.
(16 mm)
45 minutes*Steel Sidelites, Transoms
and Windows/Openings		5,760 in.²
(3.72 m²)		96 in.
(2.44 m)		96 in.
(2.44 m)		5/8 in.
(16 mm)
*Requires AHJ approval for these applications because it is tested without hose stream.
