SAFTI FIRST -GPX® Builders Series Fire Protective Doors

DOWNLOADS

20-45 Minute Fire Protective Doors and
20-45 Minute Fire Protective Windows/Openings


Category: fire rated borrowed lights | fire rated door frames | fire rated glazed assemblies...

MasterFormat: Aluminum Doors and Frames | Hollow Metal Frames | Glass Doors...


View Product Details From Manufacturer


SAFTI FIRST
100 N Hill Drive
Suite 12
Brisbane, CA 94005
Tel: (888) 653-3333
Fax: (415) 824-5900

info@safti.com

https://safti.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


GPX® Builders Series Fire Protective Doors

Product Advantages

  • GPX® Builders Series Fire Protective is a 20-45 minute fire protective hollow metal framing system.
  • Standard door profile includes 5 in. rail and 2 in. frame.
  • Narrow door profile includes 3-3/4 in. rail and 1-1/8 in. frame.
  • 10 in. ADA compliant bottom rail (can be modified with AHJ approval).
  • Can be used for interior and exterior applications.
  • Available with high performance fluoropolymer finishes by PPG, or other custom finishes including stainless steel clad or aluminum clad.
  • Doors are eligible to meet UL 1784 for smoke and draft control assemblies when used with a Category H gasket. .
  • Standard 5 year limited warranty.
  • USA manufactured for fast lead times and competitive pricing.

Product Specifications

Fire Rating

20-45 minute fire protective doors
20-45 minute fire protective windows/openings

Finish

High performance paint by PPG, or other custom finishes including stainless steel clad or aluminum clad

Application

Doors, Windows/Openings

Door Profile

5 in. rail and 2 in. standard frame
3-3/4 in. rail and 1-1/8 in. narrow frame

Door Depth

4-5 in.

Door Thickness

1-3/4 in.

Bottom Rail

10 in. (254 mm) ADA compliant*
Bottom rail can be modified with AHJ approval

Listings and Standards

GPX® Builders Series Fire Protective is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.

Listings

  • Intertek: 42263; 19124; 25739
  • HPD: 28600
  • Declare: SFT-0002

Standards

  • UL 9, UL 10B, UL 10C
  • NFPA 80, NFPA 252, NFPA 257
  • ASTM E152, ASTM E163, ASTM E2074, ASTM E2010-01
  • CAN/ULC S104, CAN/ULC S106
  • CPSC 16 CFR 1201 Cat. II
  • ANSI Z97.1

45 minute windows/openings can meet ASTM E119 / UL 263 / CAN/ULC S101 when glazed with SuperLite® II-XL 45 (for W-30 applications in the IBC or when fire resistive performance is desired).

Glazing Options

SuperClear® 45-HS

SuperClear® 45-HS-LI

SuperLite® I-XL

SuperLite® I-XL IGU

SuperLite® II-XL 45

SuperLite® I


See More


Specifications

MAXIMUM SIZES
Fire RatingGlazingApplicationMax. CV AreaMax. CV WidthMax. CV Height
20-45 MinutesSuperLite® I
SuperLite® I-XL*
SuperLite® I-XL IGU*		Windows/Openings5,760 in.²
(3.72 m²)		96 in.
(2.44 m)		96 in.
(2.44 m)
45 MinutesSuperClear® 45-HS
SuperClear® 45-HS-LI		Windows/Openings3,880 in.²
(2.50 m²)		96 in.
(2.44 m)		96 in.
(2.44 m)
45 MinutesSuperLite® II-XL 45Windows/Openings4,952 in.²
(3.19 m²)		124 in.
(3.15 m)		124 in.
(3.15 m)
Fire RatingGlazingApplicationMax. Door Opening
(Single Door)		Max. Door Opening
(Pair Door)
20-45 MinutesSuperLite® I
SuperLite® I-XL*
SuperLite® I-XL IGU*
SuperClear® 45-HS
SuperClear® 45-HS-LI
SuperLite® II-XL 45		Doors54 in. x 120 in.
(1.37 m x 3.05 m)*		96 in. x 120 in.
(2.44 m x 3.05 m)*

*SuperLite® I-XL and SuperLite® I-XL IGU may require prior AHJ approval for applications over 20 minutes as it is tested without hose stream. For maximum door sizes, continuous hinges will be required.
