SuperLite® II-XL 45 - 45 Minute Fire Resistive Glazing

Product Advantages

• Maximum fire and impact safety with hose stream and provides full radiant heat protection for all W-30 applications in the IBC.
• Largest tested and approved sizes up to 4,952 in.² (3.19 m²) in standard 1 in. (25.4 mm) profile.
• Tint-free and optically clear. Perfect for property line requirements.
• Available with Starphire Ultra-Clear® glass by Vitro.
• Approved NFRC CMA glazing component. SAFTI FIRST® has an in-house NFRC ACE Individual to assist designers with project-specific simulations or NFRC Bid Reports.
• Available in custom architectural make-ups, such as laminated glass and energy-saving insulated units with NFRC certifications when used with GPX® Architectural Series Fire Resistive framing.
• Can be customized to protect against forced entry, bullets, blast, hurricane, sound and more.
• Standard 5 year limited warranty.
• USA manufactured for fast lead times and competitive pricing.

Product Specifications

Thickness

1 in. (25 mm)

Weight

12 lbs. / sq. ft. (59 kg/m²)

Fire Rating

45 minutes with hose stream

Sound Transmission Rating

STC 37 standard profile
STC 41 when insulated with 1/4 in. Low-E

Impact Safety Rating

CPSC 16 CFR 1201 Cat. I and II, ANSI Z97.1

Visible Light Transmittance

0.789 with clear standard
0.883 with clear low-iron

Application

Doors, Sidelites, Transoms, Windows/Openings

Hard Body Impact Classification

ASTM C1629/C1629M Level 3

Soft Body Impact Classification

ASTM E695 Level 3

Surface Abrasion Resistance

ASTM D4977 Level 3

Outdoor-Indoor Transmission Class

OITC 36 standard profile
OITC 34 when insulated with 1/4 in. Low-E

Listings and Standards

SuperLite® II-XL 45 is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.

Listings

• Intertek: 32841; 56534; 23164; 29689; 51170
• UL: KCMZ.R14212; KCMZ7.R14212
• CSFM: 4075-1660:0101
• LARR: 25786
• HPD: 29036

Standards

• UL 9, UL 10B, UL 10C, UL 263
• NFPA 80, NFPA 251, NFPA 252, NFPA 257
• ASTM E119, ASTM E152, ASTM E163, ASTM E2074, ASTM E2010-01, ASTM C1629/C1629M, ASTM E695, ASTM D4977
• CPSC 16 CFR 1201 Cat. II
• ANSI Z97.1
• CAN/ULC S101, CAN/ULC S104, CAN/ULC S106
• NFRC 100, NFRC 200, NFRC 500

Framing Options

GPX® Architectural Series Fire Resistive

GPX® Builders Series Fire Protective

GPX® EZ Frame

GPX® Blast System

GPX® Ballistic Series

GPX® Hurricane

GPX® Curtain Wall
