SuperClear® 45-HS - 45 Minute Fire Protective Glazing
Product Advantages
- The clearest, most economical fire and safety rated glazing meeting all requirements for 45 minute doors, sidelites, transoms and windows/openings in large sizes.
- Meets the required hose stream test.
- Meets the CPSC Cat. II impact safety test without the need of films or laminates.
- Non-wired and tint-free.
- Can be used in interior and exterior applications.
- Approved NFRC CMA glazing component. SAFTI FIRST® has an in-house NFRC ACE Individual to assist designers with project-specific simulations or NFRC Bid Reports.
- US Pat. No. 11,479,504 with additional patents pending.
- Lifetime warranty.
- USA manufactured for fast lead times and competitive pricing.
Product Specifications
Thickness
3/4 in. (19 mm)
Weight
9 lbs. / sq. ft. (44 kg/m²)
Fire Rating
45 minutes with hose stream
Sound Transmission Rating
STC 37
Impact Safety Rating
CPSC 16 CFR 1201 Cat. I and II,
ANSI Z97.1 Class A and B,
CAN/CGSB 12.1 Class A and B
Visible Light Transmittance
83%
Application
Doors, Sidelites, Transoms, Windows/Openings
Outdoor-Indoor Transmission Class
OITC 35
Listings and Standards
SuperClear® 45-HS is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.
Listings
- Intertek: 48346; 48350; 48962
- UL: KCMZ.R14212; KCMZ7.R14212
- CSFM: 4075-1660:0500
- LARR: 26174
- HPD: 28449
- Declare: SFT-0003
Standards
- UL 9, UL 10B, UL 10C
- NFPA 80, NFPA 252, NFPA 257
- CAN/ULC S104, CAN/ULC S106
- CPSC 16 CFR 1201 Cat. I & II
- ANSI Z97.1
- CAN/CGSB 21.1
Framing Options
GPX® Architectural Series Fire Protective
GPX® Vision Kit
GPX® Builders Series Fire Protective
GPX® EZ Frame
