SuperLite® II-XL 90 - 90 Minute Fire Resistive Glazing
Product Advantages
- Maximum fire and impact safety with hose stream and full radiant heat protection.
- Largest tested and approved sizes up to 4,876 in.² (3.15 m²) in standard 1-1/2 in. (39 mm) profile.
- Tint-free and optically clear. Perfect for property line requirements.
- Acoustical value of 44 STC.
- Available with Starphire Ultra-Clear® glass by Vitro.
- Approved NFRC CMA glazing component. SAFTI FIRST® has an in-house NFRC ACE Individual to assist designers with project-specific simulations or NFRC Bid Reports.
- Available in custom architectural make-ups, such as laminated glass and energy-saving insulated units with NFRC certifications when used with GPX® Architectural Series Fire Resistive framing.
- Can be customized to protect against forced entry, bullets, blast, hurricane, sound and more.
- Standard 5 year limited warranty.
- USA manufactured for fast lead times and competitive pricing.
Product Specifications
Thickness
1-1/2 in. (39mm) standard
2-1/4 in. (57 mm) when insulated with Low-E
Weight
12 lbs. / sq. ft. (59 kg/m²)
Fire Rating
90 minutes with hose stream
Sound Transmission Rating
STC 44
Impact Safety Rating
CPSC 16 CFR 1201 Cat. I and II, ANSI Z97.1
Visible Light Transmittance
0.853 with clear standard
0.875 with clear low-iron
Application
Doors, Walls
Hard Body Impact Classification
ASTM C1629/C1629M Level 3
Soft Body Impact Classification
ASTM E695 Level 3
Surface Abrasion Resistance
ASTM D4977 Level 3
Outdoor-Indoor Transmission Class
OITC 40
NFRC Certifications with GPX Framing
0.34 U-Factor when insulated with Solarban 60
0.27 SHGC when insulated with Solarban 60
55 Condensation Resistance when insulated with Solarban 60
Listings and Standards
SuperLite® II-XL 90 is listed and labeled by Underwriters Laboratories and Intertek, nationally recognized testing laboratories approved by OSHA.
Listings
- Intertek: 32841; 56534; 29495; 51170
- UL: KCMZ.R14212; KCMZ7.R14212; U518
- CSFM: 1080-1660:0105
- LARR: 25786
- HPD: 29036
Standards
- UL 9, UL 10B, UL 10C, UL 263
- NFPA 80, NFPA 251, NFPA 252, NFPA 257
- ASTM E119, ASTM E152, ASTM E163, ASTM E2074, ASTM E2010-01, ASTM C1629/C1629M, ASTM E695, ASTM D4977
- CPSC 16 CFR 1201 Cat. II
- ANSI Z97.1
- CAN/ULC S101, CAN/ULC S104, CAN/ULC S106
- NFRC 100, NFRC 200, NFRC 500
Framing Options
GPX® Architectural Series Fire Resistive
GPX® Builders Series Temperature Rise
GPX® EZ Frame
GPX® Blast System
GPX® Ballistic Series
GPX® Hurricane
GPX® Curtain Wall
