| Narrow/Jamb Mounting Boxes | | |
 | CM-23 | Surface Box, Standard Depth Flame and Impact resistant black polymer (ABS) 1-3/4"W x 4-1/2"H x 1-1/4"D Dimensions: 3.5"L x 6"W x 2.25"H Weight: 0.25lbs. UPC:670454122223 |
 |
CM-23D |
Surface Box, Extra Deep - For wireless. Flame and Impact resistant black polymer (ABS) 1-3/4"W x 4-1/2"H X 1-1/2"D. Not compatible with CM-333 narrow SureWave(tm) battery powered touchless switch. Dimensions: 3.5"L x 6"W x 2.25"H Weight: 0.28lbs. UPC:670454122230 |
 |
CM-23CP |
Narrow/jamb stainless steel cover plate Dimensions: 5"L x 3"W x 2"H Weight: 0.03lbs. UPC:670454175229 |
| Single Gang Mounting Boxes |
|
|
 |
CM-34BL |
Surface Box, Standard Depth. Double wall flame/impact resistant black ABS, 2-3/4"W x 4-1/2"H x 1-3/4"D Dimensions: 3.25"L x 5"W x 2"H Weight: 0.2lbs. UPC:670454124548 |
 |
CM-34D |
Surface Box, Extra Deep - For wireless. Heavy duty grey polymer 2-3/4"W x 4-1/2"H x 3"D Dimensions: "L x "W x "H Weight: lbs. UPC:670454151773 |
 |
CM-34AL |
Surface Box, Standard Depth, threaded conduit entry. Heavy duty cast aluminum 2-3/4"W x 4-1/2"H x 1-3/4"D Dimensions: 3.5"L x 6"W x 2.5"H Weight: 0.63lbs. UPC:670454151049 |
 |
CM-CPC1 |
Vandal and weather resistant clear lift cover for any Camden single gang flush push button or key switch Dimensions: 7"L x 4"W x 2"H Weight: 0.25lbs. UPC:670454193896 |
 |
CM-66 |
Flush box & dress plate Standard Depth box with 7" x 7" dress plate. Heavy gauge stainless steel Dimensions: 7"L x 7"W x 2.5"H Weight: 0.98lbs. UPC:670454128553 |
 |
CM-34CP |
Single gang stainless steel cover plate Dimensions: 5"L x 3"W x 2"H Weight: 0.03lbs. UPC:670454175236 |
|
CM-120G |
Rubber gasket for any stainless steel single gang faceplate Dimensions: "L x "W x "H Weight: lbs. UPC:670454169280 |
| Double Gang/Square Mounting Boxes - Surface |
|
|
 |
CM-43CBL |
Surface Box, Standard Depth, provision for wireless. Double wall, black polymer (ABS). Dimensions: 5.25"L x 5.25"W x 2"H Weight: 0.49lbs. UPC:670454126412 |
 |
CM-43CBLA |
Surface mounting box Dimensions: "L x "W x "H Weight: lbs. |
 |
CM-43LP |
Surface Box, Shallow depth, provision for wireless, black polymer (ABS) Dimensions: 5.25"L x 5.25"W x 2"H Weight: 0.55lbs. UPC:670454187826 |
|
CM-43GMK |
Glass Mount Kit for CM-43LP Box Flame/Impact resistant, 4-1/2"W x 4-1/2"H x 2"D. For used with CM-324/325/330 Series double gang Hands Free Switches Dimensions: 5.5"L x 5.5"W x 0.25"H Weight: 0.35lbs. UPC:670454190215 |
 |
CM-53 |
Surface Box, Standard Depth, provision for wireless. Double wall, black polymer (ABS) Flame/Impact resistant, 4-1/2"W x 4-1/2"H x 2"D. For use with CM-45/46 push plate switches. Add suffix ‘A’ when used with CM-324/325/330 Series double gang Hands Free Switches. Add suffix ‘B’ when used with CM-2520 double gang vestibule switches Dimensions: 5.5"L x 5.5"W x 2.5"H Weight: 0.6lbs. UPC:670454154361 |
 |
CM-63CBL |
Surface Box, Standard Depth, provision for wireless. Flame and impact resistant black polymer (ABS) 4-1/2"W x 4-1/2"H x 2"D. For use with CM-60 6" round push plate switches Dimensions: 5.5"L x 5.5"W x 2.5"H Weight: 0.6lbs. UPC:670454128263 |
 |
CM-54CBL |
Surface Box. Standard Depth, flame/Impact resistant black polymer Dimensions: 6"L x 6"W x 4"H Weight: 0.6lbs. UPC:670454182104 |
 |
CM-540B |
Surface Box, Shallow Depth. Flame and Impact resistant black polymer (ABS) 4-13/16" x 4-13/16" x 5/8" Dimensions: 6"L x 6"W x 4"H Weight: 0.6lbs. UPC:670454165602 |
 |
CM-54i |
Surface Box (Illuminated Red/Green/Blue) Standard Depth, flame/Impact resistant black polymer (ABS) 5-1/4"W x 5-1/4"H x 2"D Dimensions: 6"L x 6"W x 4"H Weight: 0.6lbs. UPC:670454184849 |
 |
CM-44 |
Surface Box, Shallow Depth, offset mount (on jamb). Stainless Steel 4-1/2”W x 4-1/2”H x 5/8”D. For use with CM-45/46 Series Dimensions: 0.75"L x 4.75"W x 5.5"H Weight: 0.22lbs. UPC:670454126429 |
 |
CM-48AL |
Surface Box, Shallow Depth. Anodized aluminum 4-1/2"W x 4-1/2"H x 3/4"D. For use with CM-45/46 Series Dimensions: "L x "W x "H Weight: lbs. UPC:670454126825 |
 |
CM-68AL |
Surface Box, Shallow Depth. Anodized aluminum, clear 4"W x 4"H x 3/4"D. For use with CM-60 Series Dimensions: 0.75"L x 4.75"W x 5.5"H Weight: 0.13lbs. UPC:670454128577 |
|
CM-68BZ |
Surface Box, Shallow Depth. Anodized aluminum, dark bronze 4"W x 4"H x 3/4"D. For use with CM-60 Series Dimensions: 5.5"L x 5.5"W x 2.5"H Weight: lbs. UPC:670454128584 |
 |
CM-440 |
5" Dress plate, Cover for double gang or 4" square flush box. Heavy gauge stainless steel Dimensions: 9"L x 5"W x 1"H Weight: 0.25lbs. UPC:670454154835 |
 |
CM-660 |
6-1/2" Dress plate, Cover for double gang or 4" square flush box, Heavy gauge stainless steel Dimensions: 6.5"L x 6.5"W x 1"H Weight: 0.47lbs. UPC:670454154965 |
 |
CM-43CP |
Double gang stainless steel cover plate Dimensions: 5"L x 3"W x 2"H Weight: 0.03lbs. UPC:670454175243 |
|
CM-43G |
Gasket for CM-43CBL and CM-63CBL Boxes Dimensions: 8.5"L x 6"W x 0.5"H Weight: 0.02lbs. UPC:670454152350 |
| Double Gang/Square Mounting Box - Surface - Conversion Kit |
|
|
|
CM-43CBL-ADP1 |
Adaptor kit to mount SUREWAVE(tm) double gang switch on CM-43CBL surface mount box Dimensions: "L x "W x "H Weight:lbs. |
|
CM-54i-ADP1 |
Adaptor kit to mount SUREWAVE(tm) double gang switch on Aura(tm) Illuminated CM-54i (Surface) or CM-55i (flush) mount box Dimensions: "L x "W x "H Weight:lbs. |
|
CM-43CBL-ADP2 |
Adaptor kit to mount VALUEWAVE(tm) double gang switch on CM-43CBL surface mount box Dimensions: "L x "W x "H Weight:lbs. |
|
CM-43LP-ADP1 |
Adaptor kit to mount VALUEWAVE(tm) double gang switch on CM-43LP (Low Profile) surface mount box Dimensions: "L x "W x "H Weight:lbs. |
| Double Gang/Square Mounting Boxes - Flush |
|
|
 |
CM-55CBL |
Flush box, Standard Depth, flame/Impact resistant black polymer (ABS) 6-1/2"W x 6 1/2"H x 2". For use with CM-45/46 Series Dimensions: 6"L x 6"W x 4"H Weight: lbs. UPC:670454180285 |
 |
CM-55i |
Flush box (Illuminated Red/Green/Blue) Standard Depth, flame/Impact resistant black polymer (ABS) 6-1/2"W x 6-1/2"H x 2"D. For use with CM-45/46 Series Dimensions: 6"L x 6"W x 6"H Weight: 1.5lbs. UPC:670454184856 |
 |
CM-RH-DG |
Stainless Steel, Double Gang Rain Hood. Compatible with any Camden flush mount double gang switch. Dimensions: 6"L x 6"W x 4"H Weight: 0.75lbs. UPC:670454210999 |
| 4 1/2" Round Mounting Boxes - Surface |
|
|
 |
CM-47S |
Surface, Round, Standard Depth, provision for wireless. black polymer (ABS) Flame and Impact resistant, 5" x 1-3/4"D Dimensions: 5"L x 5"W x 2"H Weight: 0.49lbs. UPC:670454159793 |
 |
CM-47SER |
Surface, Round, Extra Deep, for Kinetic(tm) CM-40K Series Push Plate Switches Dimensions: 5.0"L x 5.0"W x 3.0"H Weight: 0.65lbs. UPC:670454207753 |
 |
CM-570B |
Surface Round, Shallow Depth, Flame and Impact resistant black polymer (ABS) 4-11/16"DIA x 5/8" D Dimensions: 5.5"L x 5.5"W x 2.5"H Weight: lbs. |
| 4 1/2" Round Mounting Boxes - Flush |
|
|
 |
CM-57CBL |
Flush, Round, Standard Depth, flame/Impact resistant black polymer (ABS) 6-5/8"DIA x 2"D Dimensions: 6"L x 6"W x 4"H Weight: lbs. UPC:670454180292 |
 | CM-57GR | Flush, Round (Illuminated Green/Red). Standard Depth, flame/Impact resistant black polymer (ABS) 6-5/8"DIA x 2"D Dimensions: 6"L x 6"W x 6"H Weight: 1.5lbs. UPC:670454179456 |
| 6" Round Mounting Boxes - Surface | | |
 | CM-69S | Surface, Round Standard Depth, provision for wireless. black polymer (ABS) Flame and impact resistant, 6-1/2" x 1-3/4"D Dimensions: 6.25"L x 6.25"W x 2"H Weight: 0.65lbs. UPC:670454151995 |
 | CM-69SER | Surface, Round, Extra Deep, for Kinetic(tm) CM-60K Series Push Plate Switches and 6" Round SureWave(tm) switches Dimensions: 6.25"L x 6.25"W x 3.0"H Weight: 0.65lbs. UPC:670454207760 |
