Overview


Loading Dock Seals - Classic

Built to Rite-Hite’s high standards for quality, Classic Seals offer traditional benefits with a range of options to increase durability and sealing effectiveness.

Features (Classic seal with traditional header)

  • Rugged ArmorPleat™ protection - Available on full length of side pads, ArmorPleats provide additional abrasion protection to extend the life of the dock seal. Available in high-strength, friction-resistant Durathon® fabric.

  • Head Pad Model: Traditional head pad - Foam compression head pad seals directly against trailer. Corner wear pleats provide added reinforcement.

  • Head Curtain Model: Adjustable head curtain - Pull-rope activation allows flexibility to manually adjust seal to varying trailer heights to ensure most effective coverage. Corner wear pleats provide added reinforcement.

  • Available Firefighter® header protection* - Optional Firefighter system prevents head pad from burning due to the heat buildup of compressed trailer marker lights.

Features (Classic seal with High Performance header)

  • Rugged ArmorPleat™ protection - Available on full length of side pads, ArmorPleats provide additional abrasion protection to extend the life of the dock seal. Available in high-strength, friction-resistant Durathon® fabric.

  • Triple-reinforced corner wear boots* - Multiple layers under outer Durathon friction-resistant fabric fortify corners, where earliest and most severe damage typically occurs.

  • Replaceable wear components* - Corner wear boots and head curtain face are attached with Velcro and are quickly and easily replaced, if needed, for simple, low-cost maintenance or upgrades.

  • Internal Firefighter® technology* - Triple-layer foil heat-dissipation system in header prevents burning from the heat build-up of compressed trailer marker lights.

  • Light-blocking header face* - Mini pleats close gaps caused by seal-breaking protrusions on backs of trailers.

  • Head Pad Model: Anti-sag head pad construction* - Backerless head pad with internal stabilizing panel adapts to trailer movement, preventing foam from sagging over time after repeated trailer impact and bouncing motion.

  • Head Pad Model: Head pad pop-off protection* - Unique mounting allows head pad to pivot upwards freely, preventing it from becoming pried off the wall by trailers when yard jockeys are in use.

  • Head Curtain Model: Impactable header frame* - Flexible framing resists damage if struck by trailer coming in too high.

  • Head Curtain Model: Head curtain stability system* - Self-locking design improves sealing integrity at trailer top and eliminates the need for wind straps. Prevents curtain from blowing in wind and losing contact with trailer.

  • Available PitMaster™ 4th-side sealing system* - Gaps beneath and around dock leveler and bumpers are sealed with optional PitMaster components, providing energy savings, improving cleanliness and helping pass inspections.

* Exclusive Rite-Hite feature

This product may not be sold in all countries. Contact your local Rite-Hite representative for availability.
