Overview


Rolling Fire Doors

Model Number: ERD10, ERD11, ERD20 and ERD21

Rolling Fire Door Closures

Fire and smoke must be stopped in their tracks to save property and, more importantly, protect lives. Our advanced fire rated door systems compartmentalize a fire event quickly allowing adequate time for egress from the building.

Our rolling fire rated doors have become the clear and reliable choice for building owners and designers who demand the highest level of life safety and fire protection available with the lowest cost of ownership in a modern, easily integrated package.

All fire proof doors are custom built for everyday use. Designed for fire rated openings, our fire doors provide security and access control and are for use in openings that are not part of a required means of egress. Available with several optional materials and finishes, our fire proof doors have many ways to be customized to meet your fire solutions needs.

Our advanced Fire Door Closure Systems offer industry-leading, intelligent operation that:

  • Activate thermally or electrically to contain fire and smoke spread.

  • Easily - or even automatically - reset or auto open after a fire event or power outage

Optional SmokeShield® smoke and draft control conforms to UL1784 and assures that smoke will be compartmentalized with the fire and not spread quickly throughout the facility, allowing safe egress for occupants.

Our fire proof doors are Factory Mutual Approved, listed with the California Office of the State Fire Marshal, and are UL Listed for ¾, 1 ½, 3 and 4 hours of fire protection. These doors are designed for daily use to provide security and access control, and are approved for openings that are not required means of egress.

Our overhead rolling fire doors are custom built to your specifications in our standard service door configuration or in our Firemiser™ insulated rolling fire door version for climate control solutions. See how Cornell can help you with your fire rated garage door needs today.

Rolling Steel Fire Doors are structural separations used to prevent the spread of fire and smoke throughout a building. Our Fire Doors are Factory Mutual Approved, listed with the California Office of the State Fire Marshal, and are UL Listed for ¾, 1 ½, 3 and 4 hours of fire protection. These doors are designed for daily use to provide security and access control, and are approved for openings that are not required means of egress .

Closing Systems

Choosing a fire door closing system is just as important as choosing a fire door. The advanced AlarmGard® Closing System, available in motor, chain or crank, is recommended for the highest reliability and lowest cost of ownership with an unmatched simplicity of meeting annual test and reset requirements.

Sizes
  • Standard construction up to 30' wide, 30' high.

Standard Materials and Finishes

Fire Door curtains are available in:

• 22, 20 and 18 gauge galvanized steel:

‒ Exclusive GalvaNex™ finish in Gray, Tan, White or Brown provided as standard

• 20 gauge 300 series stainless steel:

‒ #4 finish

Stamped steel or cast iron endlocks are provided per UL procedure.

Finish/gauge availability varies.

Fire Specific Options

Annunciators

Optional safety devices on provide a visual and/or audible advanced warning when the door is about to close .

Battery Back Up Devices

Available for motor, chain and crank operators, these devices prevent fire doors from closing from a power failure for up to 7 days.


FireGard Release Devices

Optional device that ties in to a building alarm system and closes a FireGard fire door upon alarm activation, rather than by melting its fusible link.

Firemiser Insulated Fire Door

When you need both fire and environmental protection, you need a Firemiser Insulated Door.

Testing Stations

Safely and conveniently test and reset the functionality of the fire door at floor level. May be flush or recess mounted.

Aesthetics

AtmoShield™ Powder Coating

Textured powder coat finish that combats the environments harsh wear and tear. This finish provides a thicker, more scratch resistant coat for added product protection.

Hood and Operator Covers

Metal cover to protect the coil or operator from exterior weather, debris or to meet OSHA or UL 325 safety requirements.


SpectraShield™ Powder Coating

Polyester finish in more than 180 colors for durability, aesthetics, superior finish life and cost effectiveness.


Trim Package

In applications where exterior aesthetics are important, such as hotels, condominiums, convention centers and parking garages, the addition of a trim package can cover unsightly hardware and contribute to the building's architecture.

Vision Windows

Improve aesthetics and visibility with one- or two-way windows incorporated in the curtain.

Performance Upgrades

High Cycle Springs

Heavy duty springs manufactured to withstand cycles of 100,000.

Seismic Performance Validation

We can provide project specific seismic calculations for all coiling doors that are mounted Face of Wall to steel or masonry. Seismic performance validation is per ASCE 7-05.

Safety and Protection

Entrapment Protection Devices

Entrapment protection devices ensure that a motorized door or grille will not close on an object. If an object enters path of closure, the entrapment protection device will stop the door or grille from closing and return it to the fully open position.

Guide-Mounted Interlocks

An electrical cutout switch to prevent motor operation if locking device is not first disengaged.

Motor Mounted Interlock

An overload sensing device that prevents damage if motor operation is attempted when the door or grille is locked. Field wired guide mounted interlocks are no longer necessary.

Rolling Door Protector (RDP)

The RDP eliminates costly fork truck damage to coiling doors by creating a physical barrier at the top of the door that absorbs impacts.

Unique Design Solutions

Sloping or Irregular Openings

Our special bottom bar designs can address these conditions.


See More


Specifications

Mounting Options
ConfigurationWall PositionWall Type
Face of WallInteriorMasonry
Between JambsExteriorStructural Steel Jambs
Drywall construction with structural steel or wood studs
