Ecoustic® Panel Raw Printed Wall Panel

Ecoustic® Raw is a restrained and subtle acoustic panel print associated more commonly with industrial hard surfaces.

Pattern Repeat: Width 47.24“ (1200mm) Height 106.3“ (2700mm).

Additional Features

Designer

Michael Young

Content

100% PET (up to 65% recycled content)

Environment

California 01350 Emissions Compliant, Declare Compliant, EPD, Greentag Level A Certified, HPD, Low VOC, No Conflict Minerals, No Fire Retardant Additives, Printing Ink US Greenguard Gold-certified + Ecologo certified, Prop 65 Compliant, Published with mindful MATERIALS, Rapidly Renewable Content, Recycled Content, Red List Compliant, Third Party Certified

Performance

• The NRC rating range for Ecoustic® Panels is between 0.30 and 1.0 depending on the panel thickness, when the panel is directly fixed to a wall.
• Increased NRC ratings may be achieved by installing Ecoustic® Panels with an air gap.
• Compared to traditional panels, the semi rigid Ecoustic® Panel + Screen is lower in weight, easier to handle and results in reduced transportation costs.

Green Star + LEED

• Green Star: Ecoustic® is Greentag Level A Certified and can achieve maximum Green Star points.
• LEED: 65% post consumer content contributes to LEED MR Credit 4 Recycled Content.

Additional Information

• - Printed Panels are available in several thicknesses, 0.31″, 0.53″, 0.98″, 1.97″.
• Minimums are required for the 0.53″ (3 boxes), 0.98″ (3 boxes), and 1.97″ (5 boxes).
• Detailed NRC ratings may be found on the panel specification document on this page.
• Natural anodized aluminum edging lengths at 9′ with counter sunk holes are available for all Ecoustic® Panel thicknesses.
• Ecoustic® is an intelligent alternative to traditional panels composed of multiple materials such as particle board, fabric, foam and adhesive.
• Ecoustic® Panels + Screens can be trimmed and installed without the need for additional finishes, which reduces labor and material costs.

NRC Rating

0.30 - 1.0

Dimensions

Panel: 47.64” x 107.1”, Print: 47.24” x 106.3” - Screen: 95.3” x 47.64”, Screen Print: 94.5” x 47.24”

Sold In

Box sets per thickness: 0.31" (8), 0.53" (5), 0.98" (6), 1.97" (3)

Flammability

AS/ISO 9705 group 1, AS/NZS 1530.3, ASTM E84 Class A, GB 8624
