Impasse® Mineral Wool Insulation Hanger System

Impasse® Mineral Wool Insulation Hanger System

  • Provides up to 3 hour fire protection in curtain wall systems
  • Patented design
  • Saves time and money over traditional jobsite installation methods
  • Ideal for factory installing curtain wall insulation
  • Easy to install
  • Requires installation of fewer mechanical attachments
  • UL approved and listed

Thermafiber® Impasse® System


Impasse® Mineral Wool Insulation Hanger System


Description:

Thermafiber® IMPASSE® curtain wall insulation system is a patented design that streamlines the installation of curtain wall insulation by changing the order of traditional installation steps to fit a more logical progression and take full advantage of the fire protective, sound control, and vapor barrier properties of FireSpan® and Safing Insulation. Traditional curtain wall insulation systems call for installation of impaling pins on spandrel panels before installation of insulation. The insulation is then impaled onto the pins. The Impasse system is unique in that the hangers are inserted into the insulation before the insulation is installed into the panels. This technique saves time and money. The Impasse® system is tested and rated with UL® laboratories and provides up to 3 hours of fire protection.

Product Options:

  • Impasse Hangers
  • Spiral Anchors
  • Locking Washers
  • FireSpan®
  • Safing

Standard Sizes:


Impasse® Mineral Wool Insulation Hanger System


Perimeter Fire Containment Systems:

UL® Approved Designs per ASTM E 2307
CW-D-1005
CW-D-1016
CW-D-2041
CW-D-2051
CW-S-2058
CW-D-1006
CW-D-1017
CW-D-2042
CW-D-2052
CW-S-2059
CW-D-1007
CW-D-2008
CW-D-2043
CW-D-2055
CW-S-2060
CW-D-1008
CW-D-2009
CW-D-2044
CW-D-2056
CW-S-2061
CW-D-1009
CW-D-2010
CW-D-2045
CW-D-2059
CW-S-2062
CW-D-1010
CW-D-2036
CW-D-2046
CW-S-2001
CW-S-2064
CW-D-1012
CW-D-2037
CW-D-2047
CW-S-2002

CW-D-1013
CW-D-2038
CW-D-2048
CW-S-2003

CW-D-1014
CW-D-2039
CW-D-2049
CW-S-2006

CW-D-1015
CW-D-2040
CW-D-2050
CW-S-2008
