Overview


METALWORKS 3D: 7220UP2M1

3D ceiling system panels are available in five different heights that can be installed up or down.

Performance
  • Define and accentuate spaces with unique 3D look
  • Reflections laminate finishes provide wood-look visual
  • Standard Tegular and 1", 2", 3", and 4" panel heights
  • Easy to install
  • Perforation option available for acoustics
  • Durable - Washable, Scrubbable, Soil-resistant


See More


Specifications

EdgeDimensionsPerforation
Square Up Tegular 9/16 in24 in x 24 in x 2 inM1 - Unperforated
Performance
Acoustics
% Open Area 0%
Fire
Fire Performance Class A (painted) / Class B (laminate)
Light Reflectance 77%
Sag/Humidity Resistance Standard
Durability Soil Resistance
Impact Resistance
Washability
Scrubbability
Physical Data
Material Metal
Texture Smooth
Surface Finish Polyester paint, acrylic latex paint on acoustically transparent membrane, or vinyl-faced membrane
Shape Rectangle
Weight 0.70 PF2
Sq Ft (Sq Ft / Carton) 4
Pieces / Carton 1
ASTM Classification Type: XX, Pattern: G
Installation Method Grid (Suspended)
