FireGuard™ Accordion Sliding Access Door

The Gold Standard in Fire Protection

Since its inception more than 40 years ago, the original fire-rated, horizontal-sliding accordion door continues to influence building code requirements and provide design professionals with unmatched flexibility and peace of mind.

Design Versatility

From the most narrow of corridors and the shortest of ceilings to openings that span over 200’ wide and 35’+ tall, FireGuard™ gives you the versatility to protect any size opening.

Curved Configurations

Flow with the gradual curve in your design or snake around structural elements. Custom radii are available to as tight as 5’.

Secure Solution

An effective deterrent to unauthorized visitors while maintaining an open plan design, FireGuard™ can replace traditional solutions for virtually any means of egress or access control.

Straight

UL listed for heights up to 30’ and unlimited widths. Custom heights are available.

• Single and bi-parting configurations available
• Unitized track system simplifies installation
• Fire-rated up to 180 minutes
• Pocket cover door provided by others
• Automatic closing system in accordance with UL 864

Curved

UL listed for heights up to 28’ and unlimited widths. Custom heights available.

• Single and bi-parting configurations available
• Standard radii are 5’ and 10’
• Custom radii > 5’ available
• Fire-rated up to 180 minutes
• Automatic closing system in accordance with UL 864

Corner Bi-part

Capable of 10′ heights and 20′ widths on each leaf.

Unitized track system simplifies installation

Perfect for stairway/escalator landings when radial configurations are not feasible.

Fire-rated up to 90 minutes

Pocket cover doors provided by others

Automatic closing system in accordance with UL 864
