Model 600 Rolling Grilles
The Model 600 Rolling Grille offers security, visibility, and ventilation in several patterns and finishes. Rolling Grills provide security against entry or theft with slide bolts or padlockable chains while the design allows visual access through the door opening space. This rolling grille also offers an emergency egress option as an additional security feature. Model 600 is constructed with vertical aluminum links and horizontal steel rods with spacer tubes and end links that ensure that the grille cannot be pulled from guides. The counterbalance assembly consists of a spring barrel which serves as a load-carrying beam. It encases the counterbalance mechanism and provides the axis around which the curtain coils.
Ideal Applications Include:
Retail - Parking Garage - Schools - Hospitals - Office buildings - Airports - Banks - Pharmacies
Benefits
High-Quality Construction
- The bottom bar is a tubular aluminum extrusion, providing stability and strength
- Extruded aluminum guides provide vertical alignment and strength
- The wool pile inserts provide smooth and quiet operation
Safety Focused
- Provides ventilation to aid in preventing any excess build-up of fumes or gases
Warranty
- 12-Months Limited Warranty against defects in materials and workmanship
Guides/Brackets/Barrel/Bottom Bar/Guides Finish
- Black Primed
- Painted steel (Beige, White or Gray)
*Center lock security pattern is also available
Not all patterns available in all sizes
Acrylic Lites
Hood Options
- Square hood and brackets
- 24-gauge galvanized steel
- Stainless steel
- 20-gauge B&S aluminum
Guide Options
Steel mountain tubes
End covers
RAL Powder Coat*
Approximately 200 powder coat options are available to complement the exterior colors of a building.
*Online color swatches are only digital reproductions of actual standards and will vary in appearance due to differences in monitor and video card output. These digital representations should not be used to finalize color selection(s). Actual physical representation may vary slightly in color.
