ME-500 Stage Supports

For a quick changeover on your major venue events, ME-500 stage supports are designed to save you time.

Need a quick stage changeover? Just unfold the ME-500 portable stage understructure, rotate the retractable locator assemblies to accept the appropriate number of deck corners, and set the decks in place. There are no loose parts or tools needed, so set up is fast and easy. In fact, because there are 75% fewer elements touching the floor, leveling time is drastically reduced when compared to other systems that require an under structure with every deck. Aisles under the stage allow easy access to wiring and road-case storage. To strike, stage supports fold down and become their own storage system, stacking securely on top of each other.

Product Features

Eliminate time spent assembling components or using tools. Perform on a stable, wobble-free portable platform.

Reduce teardown time because the supports stack securely on top of each other without straps or bins. Use minimal storage space (for example, 24 support assemblies store in 96 sq. ft.).

Save time with fewer stage supports to set up and tear down as decks bridge both front-to-back and side-to-side. Greatly reduce leveling time because 75% fewer elements contact the floor when compared to other systems that have one under structure under each deck. Minimize your initial investment and storage space requirements because fewer supports are required. Utilize convenient, unobstructed storage space beneath the performance stage.

Save setup time by connecting one to four deck corners (no matter what the stage configuration). Save setup time because the decks automatically align and the stage sections automatically connect together as the decks fasten on the conical locator nodes.

Compensate for uneven floors with five inches of easy, fine-adjustment leveling. Save costs because tough, 3/4″ Acme-thread screw resists damage (compared to typical “V” threads). Protect floor surfaces with sure-grip three-inch diameter urethane pads.

Handle the support system more easily than you would a heavier steel system. Reduce maintenance costs as the tough, aircraft-alloy composition and the scratch-resistant, baked-on finish resist damage.

Select stage heights in two-inch increments. Reference nominal heights quickly on inner legs. Ensure maximum security with large, 5/8″ diameter height adjustment pin.

Product Details

Applications

Major Events & Staging
