SFS Group -#9 Evergrip® Bi-Met Metal to Wood Screw, Pan Head, 304 Stainless, BM-S3-9-PN

Features and Benefits

Provides the corrosion resistance of stainless with the drill performance of a carbon steel fastener
T25 drive pan head provides driving stability
Head and shank are 304SS

Category: fasteners | screws | stainless steel fasteners...

MasterFormat: Connectors and Supports*

SFS Group
1045 Spring Street
Wyomissing, PA 19610
Tel: (800) 234-4533
Fax: (888) 485-4225

Overview

#9 Evergrip® Bi-Met Metal to Wood Screw, Pan Head, 304 Stainless, BM-S3-9-PN

Features and Benefits

Provides the corrosion resistance of stainless with the drill performance of a carbon steel fastener
T25 drive pan head provides driving stability
Head and shank are 304SS
Welded carbon steel sharp point for fast installation
Assembled stainless bond seal washer
Long life fastener limited warranty

Application

Metal panel to wood where corrosion resistance of 304SS is required due to atmosphere or wood treatments

Guidance

Install fasteners with 0-2500 rpm screw gun equipped with depth sensing nose piece.
Special care needs to be taken when installing into wood substrate less than 1" in thickness. Stripping or partially stripping the fastener out during installation compromises the clamp load and can affect the performance of the fastener.
Use of impact guns or hammer drills is not recommended.

Specifications
