Single Reflective Insulation
The Reflectix® Single Reflective Insulation is ideal for applications that only require a single reflective (side of the product), or a job that specifies a white interior wall surface. As with our Double Reflective Insulation, ease of handling and installation is one of the key characteristics, contributing to a reduction in labor cost (during installation). This product is typically installed in Metal or Post Frame Buildings and is available through Contractor Sales Groups or Industrial / Commercial Building Product Suppliers.
Description:
- The product consists of one 96% reflective layer of film bonded to two internal layers of heavy gauge polyethylene bubbles (total thickness 5/16”).
- A wide variety of widths and lengths are manufactured. (Please refer to “Product Codes/Sizes” below.)
- Product Benefits (R-value and/or Radiant Barrier) vary per application. Please refer to www.reflectixinc.com/r-values, or the webpage that contains the specific application of interest.
- A Single Bubble product configuration is also available for special applications, on request.
Applications:Metal Buildings / Post Frame Buildings
- Roof Systems
- Wall Systems
Product Codes/Sizes:Specific applications within a category will contain Recommended Products that are best suited for a particular installation. Please refer to specific application webpages for this more detailed recommendation.
Metal Buildings / Post Frame Buildings
- RDBW16100 (16“ x 100’) - 133 sq. ft.
- RDBW24100 (24“ x 100’) - 200 sq. ft.
- RDBW48100 (48” x 100’) - 400 sq. ft.
- RDBW48125 (48” x 125’) - 500 sq. ft.
