All Glass Entrance Doors
All Glass Entrance Doors
PRL offers a stunning selection of frameless all-glass doors for commercial and residential entryways. Available in standard and custom all-glass door styles, our streamlined door rails have minimal aluminum glass supports and door hardware that create an expansive, frameless, all-glass door appearance providing a spectacular all-glass view.
We offer five standard all-glass door styles in heavy tempered and tempered laminated glass thicknesses ranging from 3/8” to ¾”; our P style all-glass door, BP style, F style, A style and WS450 all-glass door style. Available with continuous horizontal top and bottom rails, corner and patch rails, Euro patch fitting hardware or overhead and floor closer hardware, PRL’s selection of all-glass door styles provide quality and class to meet your needs.
Engineered to accommodate any type of hardware such as automatic and balance door hardware, mechanical or electrical access controls and standard hydraulic swing door controls, PRL’s standard door rail series use a wet or dry glazing method with high strength controlled compression.
Available in an assortment of hardware and door rail finishes such as brushed and polished stainless steel, satin and polished brass, clear and bronze anodized aluminum, Kynar paint and custom powder coat, PRL offers a will complement your all-glass door entryway with style.
FRAMELESS ALL-GLASS DOORS:
At PRL Glass Systems, Inc. we manufacture an extensive selection of expertly crafted frameless all-glass entrance doors that are sure to please. The beauty of all-glass doors is they appear frameless allowing for maximum vision and minimal obstruction to your building entry.
Our streamlined door rails offer minimal metal (aluminum) glass supports and door hardware attachment bases. PL-Standard rail series are designed to capture various thicknesses of glass ranging from 3/8”, 1/0” to ¾”. Glass is set into PL-Standard rails through a wet/dry glazing method using a high strength controlled compression. Our rails are engineered to accommodate any type of hardware from standard hydraulic swing door control, balanced door hardware, automatic door hardware to mechanical/electric access controls.
We extrude a wide selection of captivating tempered frameless all-glass doors in standard and custom styles.
Available in heavy tempered glass or tempered laminated glass PRL offers 3/8”, ½”, 5/8” and ¾” thicknesses.
Once again PRL has thought of it all, raised the bar and is able to meet your every need!
At PRL we truly are your One-Stop-Shop! We offer complete system packages that include all-glass door hardware, framing and a wide selection of rail styles and patch fittings.
Daunted by the decision making process? Choosing an all-glass door design depends on many factors such as aesthetics, ADA codes, hardware requirements and whether an exterior or interior application is needed. At PRL our team of professional experts can assist you with these decisions guiding you every step of the way!
DOOR STYLES OFFERED:
P-Style All Glass Door:
Our P-Style all-glass doors offer continuous horizontal top and bottom rails.
Hardware for overhead closer (OHC) top end load arm and bottom.
Hardware for floor closers top walking beam pivot and bottom arm.
Available Metal Finishes: Stainless steel (brushed #4 or polished #8), brass (satin or polished), anodized aluminum (clear & bronze), custom powder coat or Kynar paint.
Available For: All PL-Series rails (Height: 3 3/8” - 10") and custom.
BP-Style All Glass Door:
The BP-Style all-glass door has a corner patch rail in a 9 ½” patch rail or Euro patch fittings section located at the top pivot corner, with continuous horizontal bottom rails from any PL-Series Rails.
Hardware for overhead closer (OHC); top shorty arm & standard bottom pivot.
Hardware for floor closers; walking beam top pivot and bottom pivot.
Euro patch fittings hardware for overhead closer (OHC) surface mount top pivot and surface mount bottom pivot.
Hardware for floor closer; walking beam pivot or surface mount pivot
Available Metal Finishes: Stainless steel (brushed #4 or polished #8), brass (satin or polished), anodized aluminum (clear & bronze), custom powder coat or Kynar paint.
Available For: All PL-Series rails or PL-Euro series patch fittings (Dimensions: 2" x 6 ½”).
F-Style All Glass Door:
Our F-Style all-glass door offers patch rails or Euro patch fittings at the top and bottom pivot corners and at one leading corner of the door for accommodating a lock in a 9-1/2" patch rail or euro patch lock.
Available Metal Finishes: Stainless steel (brushed #4 or polished #8), brass (satin or polished), anodized aluminum (clear & bronze), custom powder coat or Kynar paint.
Available For: All PL-Series rails or PL-Euro Series fittings.
A-Style All Glass Door:
The A-Style all-glass door has corner 9-1/2” patch rails or euro patch fittings at the top and bottom pivot corners (no lock fitting).
Available Metal Finishes: Stainless steel (brushed #4 or polished #8), brass (satin or polished), anodized aluminum (clear & bronze), custom powder coat or Kynar paint.
Available For: All PL-Series rails or PL-Euro Series fittings.
Custom All Glass Door:
We also offer multiple choices of top rails to suit aesthetic and hardware needs. All doors are produced to specific and precise size requirements in widths and height. We here at PRL pride ourselves in being able to offer custom configurations, height, width or off-set to suit the most demanding and different design solutions.
Custom Oversize
All Glass Doors
Complete systems for interior & exterior oversize doors we provide heavy-duty hardware to accommodate special width or height. Whether your all-glass entryway calls for multiple glass door configurations, oversized doors, custom profiles, or sandblasted tempered glass design, we can fulfill your requirements with our unlimited glass type options and metal finishes. With PRL the possibilities are endless.
Dry Set & Wet Set Door Rail Patch Fittings
At PRL, we supply an incomparable collection of dry set and wet set door rail patch fittings for all-glass doors and entryways. Fabricated in-house from first-rate materials, we offer the choice of two eye-catching tapered and squared profiles for our dry set and wet set rail patch fittings.
Our door rail patch fittings measure 9 ½” long and accommodate glass thicknesses ranging from 3/8” to ¾”. Offering clad widths ranging from 1 7/8” to 2 5/16” and non-clad widths ranging from 1 ¾” to 2 3/16”, PRL can meet your project’s needs.
Available in a medley of premium standard and custom finishes, PRL offers quality dry and wet set rail patch fittings with sophistication. Select from our beautiful standard finishes such as clad brushed and clad polished stainless steel, clad, or clear anodize. Or choose from our lavish custom finishes such as powder coat, Kynar and custom paint, or custom anodize to accent your all-glass entry with refinement.
DRY SET & WET SET DOOR RAIL PATCH FITTINGS:
For all-glass doors and entryways PRL offers premium, top-of-the-line dry set and wet set door rail patch fittings in tapered and squared profiles. Fabricated from the finest materials to ensure durability our rail patch fittings stand above the rest.
Available in an assortment of spectacular finishes for glass door thicknesses ranging from 3/8” - ¾”, PRL offers dry and wet set door rail patch fittings to meet your needs and enhance your all-glass doors and entrances in style.
PRL’S DRY SET DOOR RAIL PATCH FITTINGS:
PL-150 Tapered Dry Set Rail Patch Fitting:
Our PL-150 tapered dry set rail patch fitting is designed to accommodate 3/8” and ½” glass door thicknesses. 9 ½” long and available in a variety of finishes, PRL offers a top-quality dry set rail patch fitting for your all-glass doors and entryways.
Specifications:
Glazing: Dry
Length: 9 ½”
Clad Width: 2 1/16”
Non-Clad Width: 1 15/16”
Glass Thicknesses: 3/8” and ½”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors
PL-175 Tapered Dry Set Rail Patch Fitting:
For glass door thicknesses of 5/8” and ¾” PRL fabricated the PL-175 tapered dry set rail patch fitting. Extruded in-house, this 9 ½” long fitting is available in an assortment of outstanding finishes for your all-glass entrances and doors.
Specifications:
Glazing: Dry
Length: 9 ½”
Clad Width: 2 5/16”
Non-Clad Width: 2 3/16”
Glass Thicknesses: 5/8” and ¾”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors.
PL-350 Squared Dry Set Rail Patch Fitting:
PRL’s PL-350 squared dry set rail patch fitting is designed to accommodate 3/8” and ½” all-glass door entries. Crafted from premium, durable, materials and available in a variety of exceptional finishes, the PL-350 dry set rail patch fitting measures 9 ½” long.
Specifications:
Glazing: Dry
Length: 9 ½”
Clad Width: 2 1/16”
Non-Clad Width: 1 15/16”
Glass Thicknesses: 3/8” and ½”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors.
PL-375 Squared Dry Set Rail Patch Fitting:
For glass door thicknesses of 5/8” and ¾” PRL fabricated the PL-375 squared dry set rail patch fitting. Extruded in-house, this 9 ½” long fitting is available in an assortment of outstanding finishes for your all-glass entrances and doors.
Specifications:
Glazing: Dry
Length: 9 ½”
Clad Width: 2 5/16”
Non-Clad Width: 2 3/16”
Glass Thicknesses: 5/8” and ¾”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors.
PL-150 Tapered Wet Set Rail Patch Fitting:
Our PL-150 tapered wet set rail patch fitting is designed to accommodate 3/8” and ½” glass door thicknesses. 9 ½” long and available in a variety of finishes, PRL offers a top-quality wet set rail patch fitting for your all-glass doors and entryways.
Specifications:
Glazing: Wet
Length: 9 ½”
Clad Width: 1 7/8”
Non-Clad Width: 1 ¾”
Glass Thicknesses: 3/8” and ½”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors.
PL-175 Tapered Wet Set Rail Patch Fitting:
For glass door thicknesses of 5/8” and ¾” PRL fabricated the PL-175 tapered wet set rail patch fitting. Extruded in-house, this 9 ½” long fitting is available in an assortment of outstanding finishes for your all-glass entrances and doors.
Specifications:
Glazing: Wet
Length: 9 ½”
Clad Width: 1 7/8”
Non-Clad Width: 1 ¾”
Glass Thicknesses: 5/8” and ¾”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors.
PL-350 Squared Wet Set Rail Patch Fitting:
PRL’s PL-350 squared wet set rail patch fitting is designed to accommodate 3/8” and ½” all-glass door entries. Crafted from premium, durable, materials and available in a variety of exceptional finishes, the PL-350 wet set rail patch fitting measures 9 ½” long.
Specifications:
Glazing: Wet
Length: 9 ½”
Clad Width: 1 7/8”
Non-Clad Width: 1 ¾”
Glass Thicknesses: 3/8” and ½”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors.
PL-375 Squared Wet Set Rail Patch Fitting:
For glass door thicknesses of 5/8” and ¾” PRL fabricated the PL-375 squared wet set rail patch fitting. Extruded in-house, this 9 ½” long fitting is available in an assortment of outstanding finishes for your all-glass entrances and doors.
Specifications:
Glazing: Wet
Length: 9 ½”
Clad Width: 1 7/8”
Non-Clad Width: 1 ¾”
Glass Thicknesses: 5/8” and ¾”
Standard Finishes Available:
Clad Brushed Stainless Steel (#4)
Clad Polished Stainless Steel (#8)
Clad Finish
Clear Anodize
Custom Finishes Available:
Powder Coat
Custom Paint
Kynar Paint
Custom Anodize
Custom lengths available for oversized doors.
PRL’s Samson Hydraulic Door Patch Fittings
PRL’s Samson hydraulic door patch fittings render an intelligent, resourceful design for interior, pivoting, all-glass doors. Designed to be mounted without a concrete recess, the Samson’s hydraulic closer is built into the bottom fitting providing quick, easy and cost effective installation without the need for digging.
We offer two heavy-duty bottom hydraulic patch fittings. Suitable for single or double action doors, our Samson door patch fittings can accommodate 3/8” to 9/16” glass thicknesses.
PRL’s Samson door patch fittings are an excellent solution when overhead and traditional floor spring closers can’t be used. Bearing a petite profile, the hydraulic closer’s device is concealed in a clever, compact design providing an impressive alternative to conventional closers and affording a clean, fluid expression for your all-glass entry.
