Sectional Steel Doors 432

Sectional steel door model 432 offer a 2" (51 mm) panel thickness, a nominal 24-gauge ribbed galvanized steel exterior, and a poly-bonded back cover. Polystyrene insulation provides an R-value of 7.35. A variety of options makes this door an economical solution for applications requiring a medium-duty insulated steel door.

Overview

Product Specifications

Standard Max Width

20'2" (6147 mm)

Standard Max Height

16'1" (4902 mm)

Nominal thickness

2" (51 mm)

Exterior steel

26-gauge galvanized steel

Back cover

Poly-bonded laminate

Insulation

Expanded polystyrene

R-value

7.35 (1.29 W/Msq)

Exterior surface

Ribbed

Wind Load Compliance

FBC approved wind load options available

End stiles

16-gauge steel

Center stiles

16-gauge steel

Standard mounting

Angle mount

Standard track

2" (51 mm)

Standard springs

10,000 cycle

Weather Stripping

Standard on bottom

Operation

Manual pull rope or electric operator

Finish

White or Industrial Brown baked-on polyester

Lock

Interior mounted slide lock

• 1-year limited

Enhancements

• Chain Hoist or Electric Operator is recommended for doors above 10’ tall or more than 400 pounds
• 26-gauge galvanized steel back cover
• High impact polystyrene (HIPS) back cover
• Bottom sensing edge
• Full sash section with 1/8" (3 mm) DSB, insulated; 1/8" (3 mm) and 1/4" (6 mm) acrylic
• Individual lites with 1/2" (13 mm) DSB
• 3" (76 mm) track
• Higher-cycle springs in 25k, 50k, 75k, 100k cycles
• Exhaust ports
• Jamb weather seals
• Bottom strips; including: looped PVC weatherstrips, flexible PVC astragal weatherstrips, and double-contact weatherstrips
• Reinforcing struts of roll-formed, galvanized steel
• Movable center posts for 2" (51 mm) or 3" (76 mm) tracks that roll away, with automatic safety catches that prevent door closure when posts are removed
• Tumbler keyed lock
• Window Glazing Options
• Warehouse Package - Quick install system available
• Impact Section Available
