Overview


Architectural Thin Brick

METROBRICK is a true kiln fired thin brick. Manufactured at 5/8″ thick with strict sizing to meet the needs of architectural precast, tilt-up and field applied applications. METROBRICK thin brick offers field, corners and edge caps in modular, king, norman and utility size.

THIN BRICK OPTIONS

METROBRICK® Thin Brick has the colors, sizes and textures to enhance any building. Choose just the right combination of color and texture or custom blend colors for even more options. Fast Ship colors and blends are also available for quick turnaround.

METROBRICK THIN BRICK COLORS

METROBRICK Thin Brick offers both single tone and range color options. METROBRICK’s single tone colors are a pleasing mix of natural earth tones. The single tone thin bricks have slight color variation. METROBRICK’s range color thin bricks replicate the shade variation found in traditional brick making. There are a variety of hues and tones from brick to brick in the range colors.

TEXTURE OPTIONS

METROBRICK is available in Smooth, Velour, Wire Cut, Ironspot and Vintage textures. Choose the texture that best fits the application. Ironspot can be added to any texture. However, Ironspot does not show as well in a Wire Cut texture. The Vintage texture is shown on the right. With Vintage, you can add the look of a distressed brick to any wall system, including precast and tilt-up.


See More


Specifications

Thin Brick Single Tone Colors
101 Commons105 Fieldstone107 Parkway108 Brownstone
205 Marketplace220 Courtyard310 Main Street320 Schoolhouse Red
505 Monument507 Empire705 Graphite Premium Color710 Charcoal Premium Color
Thin Brick Range Colors
151 Commons Flashed155 Fieldstone Flashed250 Courtyard Flashed255 Marketplace Flashed
350 Main Street Flashed365 Schoolhouse Red Flashed458 Brownstone Flashed
Modular Size
Modular 2 1/4″ x 7 5/8″Modular Corner 2 1/4″ x 3 5/8″ x 7 5/8″135° Modular Corner 2 1/4″ x 3 5/8″ x 7 5/8″Modular Edge Cap 2 1/4″ x 3 5/8″x 7 5/8″
King Size
King2 5/8″ x 9 5/8″King Edge Cap2 5/8″ x 2 3/4″ x 9 5/8″King Corner2 5/8″ x 2 3/4″ x 9 5/8″
Norman Size
Norman2 1/4″ x 11 5/8″Norman Corner2 1/4″ x 3 5/8″ x 11 5/8″Norman Edge Cap3 5/8″ x 2 1/4″ x 11 5/8″
Utility Size
Utility3 5/8″ x 11 5/8″Utility Corner3 5/8″ x 3 5/8″ x 11 5/8″Utility Edge Cap3 5/8″ x 3 5/8″ x 11 5/8″
Estimating
Modular Field
(2 1/4″ x 7 5/8″)
7.0 pcs./sq.ft.
King Field
(2 5/8″ x 9 5/8″)
4.8 pcs./sq.ft.
Norman Field
(2 1/4″ x 11 5/8″)
4.8 pcs./sq.ft.
Utility Field
(3 5/8″ x 11 5/8″)
3.0 pcs./sq.ft.
Estimating
Modular Corner
(2 1/4″ x 7 5/8″)
4.7 pcs./ln.ft.
135° Modular Corner
(2 1/4″ x 7 5/8″)
4.7 pcs./ln.ft.
King Corner
(2 5/8″ x 9 5/8″)
4.5 pcs./ln.ft.
Norman Corner
(2 1/4″ x 11 5/8″)
4.7 pcs./ln.ft.
Utility Corner
(3 5/8″ x 11 5/8″)
43.0 pcs./ln.ft.
Estimating
Modular
(2 1/4″ x 5/8″ x 7 5/8″)
7.0 pcs./ln.ft.
King
(2 5/8″ x 2 3/4″ x 9 5/8″)
4.8 pcs./sq.ft.
Norman
(2 1/4″ x 3 5/8″ x 11 5/8″)
4.8 pcs./sq.ft.
Utility
(3 5/8″ x 3 5/8″ x 11 5/8″)
4.8 pcs./sq.ft.
Thin Brick Texture Options
SmoothWire cutVintageVelour
Ironspot
Fast Ship Single Tone & Range Color Options
105 Fieldstone505 Monument507 Empire310 Main Street
320 Schoolhouse Red710 Charcoal*Premium Color350 Main Street Flashed365 Schoolhouse Red Flashed
458 Brownstone Flashed
Fast Ship Blend Options
Fast Ship Blend 1 60% 350 Main Street Flashed 60% 458 Brownstone Flashed 10% 710 CharcoalFast Ship Blend 2 70% 105 Fieldstone 20% 505 Monument 10% 507 EmpireFast Ship Blend 3 90% 458 Brownstone Flashed 10% 710 CharcoalFast Ship Blend 4 70% 505 Monument 30% 507 Empire
Fast Ship Blend 5 70% 507 Empire 20% 505 Monument 10% 710 CharcoalFast Ship Blend 6 50% 350 Main Street Flashed 30% 310 Main Street 20% 458 Brownstone FlashedFast Ship Blend 7 70% 320 Schoolhouse Red 20% 458 Brownstone Flashed 10% 710 Charcoal
Available Fast Ship Shapes
Modular 2 1/4″ x 7 5/8″Modular Corner 2 1/4″ x 3 5/8″ x 7 5/8″Modular Edge Cap 2 1/4″ x 3 5/8″x 7 5/8″
