Maxxon Corporation -Acousti-Mat® 1/8 Sound Control System

DOWNLOADS

  • Economical, low-profile entangled mesh mat
  • Code minimum sound control
  • Low profile system - total system height less than 1”
  • Multifamily, light commercial and low-rise hotels/motels


System Height


Category: 096000 | acoustic underlayment | insulation...

MasterFormat: Acoustic Underlayment | Tiling | Tile-Setting Materials*...


View Product Details From Manufacturer


Maxxon Corporation
920 Hamel Road
P.O. Box 253
Hamel, MN 55340
Tel: (800) 356-7887
Fax: (763) 478-2431

info@maxxon.com

https://maxxon.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Acousti-Mat® 1/8 Sound Control System

  • Economical, low-profile entangled mesh mat
  • Code minimum sound control
  • Low profile system - total system height less than 1”
  • Multifamily, light commercial and low-rise hotels/motels


System Height

  • 1/8" Profile Height / <1" Total System Height

Application
Multifamily, light commercial, low-rise hotels/motels.

Subfloor
Interior wood, concrete, steel deck, mass timber.


See More


Specifications

Technical Data
PackagingRoll 60 in. (152.4 cm) by 120 ft (36.6 m)
Storage TemperatureKeep in a dry, cool place
Coverage600 ft² (55.7 m²)
ColorClear with water-resistant white fabric
Installation TemperatureAbove 50 ˚F (10 ˚C) for at least 24 hours
UL Fire Resistance-Rated Designs - UL Design
G230J924L212L515L533L551L574M504
G516J927L501L516L534L552L576M505
G524J931L502L517L535L556L577M506
G551J957L503L518L536L557L579M507
G553J958L504L519L537L558L581M508
G560J991L505L520L538L560L583M510
G561J994L506L522L539L562L585M511
G563L006L507L523L540L563L588M513
G566L201L508L524L541L564L589M514
G574L202L509L525L542L565L590M515
G587L206L510L526L543L567L592M517
G597L208L511L527L545L569L593M518
J917L209L512L528L546L570M500M519
J919L210L513L529L547L571M502M530
J920L211L514L530L549L573M503M531
UL Fire Resistance-Rated Designs - ULC Design
I530L201L512M501M514M521
L003L511M500M503M520
Sample USGBC LEED Credit Areas*
ProjectCreditCategory
Environmental QualityEQ 2Low Emitting Materials
EQ 4Indoor Air Quality Assessment
EQ 9Acoustic Performance

* Credits may vary depending on project type and Maxxon products used.
