Earth Shield® NB190 Modified Chloroprene Rubber Hydrophilic Waterstop

Type NB190® is a modern, hydrophilic chloroprene rubber waterstop with unmatched durability and water sealing capabilities. Manufactured NON-BENTONITE, modified chloroprene rubber, Type NB190® more than doubles its original size (400% in 36 days) when exposed to water. This expansion creates an effective compression seal within joints of limited to no movement. Type NB190® can expand and reexpand unlimited times with virtually no loss of physical properties. Additionally, Type NB190® has excellent resistance to many chemicals, is heat-resistant, and is safe for drinking water (NSF 61 certified).

Earth Shield® Modified Chloroprene Rubber Hydrophilic Waterstop is used as a fluid-tight diaphragm, running along the joint, for water treatment plants, wastewater treatment plants, and fluid containment structures. Earth Shield® Modified Chloroprene Rubber Hydrophilic Waterstops are only intended for non-moving construction joints.

Earth Shield® Type NB190® Hydrophilic Waterstop Paste is used in concrete cold joints, precast joints, tunnel segments, pipe penetrations, and as an optional adhesive for Type NB190® hydrophilic chloroprene rubber waterstops. The product has a 250% expansion when immersed in fresh water for 30 days.
