Overview


In-Wall Carrier - 6800

In-Wall Carrier

Model 6800 In-wall floor mounted fixture carrier: Two 2½” x 1½” x 1/8” thick structural steel uprights having 6” x 3" x 3/8” thick welded steel 4-bolt floor flanges, supplied with ‘U’ bolts and hardware. For use in conjunction with Haws in-wall mounting plates 6700, 6700.4, 6710, 6715, 6717, or 6776, for extra heavy duty fixture support. Fits inside standard 2” x 4” wall construction. Suitable for use with either 3/8" or 1/2" concrete anchors (by others). Includes mounting holes for plumbing stub out bracket and electrical boxes. Exceeds requirements when tested in accordance to ASME Standard A112.6.1M. Design was independently verified as suitable to meet HCAI and CBC anchor spacing requirements.

Prop 65 Warning. For California Residents Warning: This product contains a chemical known to the State of California to cause cancer and/or birth defects or other reproductive harm.

Specifications

Model 6800 In-wall floor mounted fixture carrier: Two 2½” x 1½” x 1/8” thick structural steel uprights having 6” x 3" x 3/8” thick welded steel 4-bolt floor flanges, supplied with ‘U’ bolts and hardware. For use in conjunction with Haws in-wall mounting plates 6700, 6700.4, 6710, 6715, 6717, or 6776, for extra heavy duty fixture support. Fits inside standard 2” x 4” wall construction. Suitable for use with either 3/8" or 1/2" concrete anchors (by others). Includes mounting holes for plumbing stub out bracket and electrical boxes. Exceeds requirements when tested in accordance to ASME Standard A112.6.1M. Design was independently verified as suitable to meet HCAI and CBC anchor spacing requirements.
