ADA Low Profile Vandal-Resistant Fountain and Bottle Filler - 1107L-1920
ADA Low Profile Vandal-Resistant Fountain and Bottle Filler
The Haws 1107L-1920 vandal-resistant low profile barrier-free drinking fountain and bottle filler use patented stainless steel, push-button activated, valve assemblies allowing for front access stream adjustment as well as cartridge and strainer access. This wall mounted fountain offers the 'only' all stainless-steel valve body that is machined out of solid bar stock, is fully serviceable through the front of the push button assembly offering access to the water control cartridge and integral water supply strainer, and has front access to the water stream height adjustment for easy maintenance without having to remove the valve.
- 100% lead free waterways
- Vandal resistant components include bubbler, buttons, drain and bottom plates
- 1 gpm (3.78 L) bottle filler laminar flow
- 14 gauge Type 304 Stainless Steel design with integral mounting plate provides a well constructed sturdy fountain
- Easy maintenance with front access to valve adjustment and cartridge replacement
- Beautiful satin finish resists stains and corrosion
- Soft rounded corners prevent mishaps and other accidents that may occur once the fountain is installed
- One-piece stamped basin with low-profile design make for an aesthetically pleasing and durable unit
- The bottle filler requires a mounting plate; either the 6700 in-wall or the 6700R on-wall support plate.
Model meets all current Federal Regulations for the disabled including those in the Americans with Disabilities Act. Haws manufactures drinking fountains, faucets and electric water coolers to be lead-free by all known definitions including NSF/ANSI/CAN 61- Section 9, NSF/ANSI/CAN 372, California Proposition 65, and the Federal Safe Drinking Water Act. Product is compliant to California Health and Safety Code 116875 (AB 1953-2006), and NSF/ANSI/CAN 61: Q ≤ 1.
Prop 65 Warning. For California Residents Warning: This product contains a chemical known to the State of California to cause cancer and/or birth defects or other reproductive harm.
Certifications - CSA Certified
- ADA Compliant
- NSF/ANSI/CAN 61-2020 with Q ≤ 1
SpecificationsModel 1107L-1920 wall-mounted vandal-resistant ADA drinking fountain and bottle filler shall include a 14-gauge Type 304 Stainless Steel satin-finish basin with integral 1/4” stainless steel mounting plate, 14 gauge bottle filler bracket, vandal-resistant push button operated stainless steel valves with front accessible cartridge and flow adjustment that provide 100% lead-free waterways, polished chrome plated brass vandal-resistant bubbler head with integral laminar anti-squirt flow, 1 gpm (3.78 L) laminar flow bottle filler, polished chrome-plated brass vandal-resistant waste strainer, vandal-resistant bottom plates, and 1-1/4” NPT integral trap. Unit can be mounted to meet ADA or Child ADA specifications. The botte filler requires a mounting plate; either the Haws model 6700 in-wall or the 6700R on-wall support plate.
