Elkay® -ezH2O® In-Wall Bottle Filling Station Non-Filtered Refrigerated Stainless-EZWS8K

DOWNLOADS

The Elkay EZH2O® Bottle Filling Station delivers a clean quick water bottle fill and enhances sustainability by minimizing our dependency on disposable plastic bottles. Fully recessed in-wall design. Sanitary no-touch sensor activation with automatic 20-second shut-off timer.


Category: ADA-compliant drinking water dispensers | accessible products | chilled water dispenser...

MasterFormat: Plumbing Fixtures | Drinking Fountains and Water Coolers | Drinking Fountains



Elkay®
1333 Butterfield Road
Suite 200
Downers Grove, IL 60515
Tel: (800) 476-4106

CustCare@Elkay.com

https://www.elkay.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


ezH2O® In-Wall Bottle Filling Station Non-Filtered Refrigerated Stainless-EZWS8K

The Elkay EZH2O® Bottle Filling Station delivers a clean quick water bottle fill and enhances sustainability by minimizing our dependency on disposable plastic bottles. Fully recessed in-wall design. Sanitary no-touch sensor activation with automatic 20-second shut-off timer.

Features

  • Designed as a stand-alone unit or to be paired with Elkay® SwirlFlo or Soft Sides® architectural fountains
  • Hermetically sealed refrigeration system provides chilled water to satisfy thirst
  • Touchless, sensor-activated bottle filler designed for easy use
  • Fill rate is 1.1 GPM
  • Green Ticker™ informs user of number of 20 oz. plastic water bottles saved from waste
  • Key plastic components are manufactured with silver ion antimicrobial agent helping to provide clean, stain- and odor-free surfaces
  • Silver ion antimicrobial protection on key plastic components to inhibit the growth of mold and mildew
  • Real drain system eliminates standing water
  • Rated for indoor use


See More


Specifications

Specifications
Material

Stainless Steel

Number of Stations

1

Features

Antimicrobial
Green Ticker™
Hands Free
Laminar Flow
Real Drain

Power

115V/60Hz

Dimensions

L: 19-3/4"
W: 3-1/2"
H: 40-13/16"

Bubbler Style

No Bubbler

Mounting Type

Wall Mount (In-Wall Frame/Plate)

Chilling Capacity

8.0 GPH

Installation Location

Indoor

Shipping Dimensions

L: 28-1/4"
W: 39-3/4"
H: 22"

Shipping Weight

63 LBS

Included With Product

Bottle Filler (EZWSM8C)
Chiller (ECH8)

Ships In Multiple Boxes

Yes

ADA

Yes

Filtered

No

Code Compliance

CSA C22.2 No. 120
UL 399
NSF 61
NSF 372

Note

Requires mounting frame MFWS100 which is ordered seperately for early installation.
