Overview


ezH2O® BFS with Integral SwirlFlo® Fountain Filtered Non-Refrigerated Stainless-LZWS-EDFPBM114K

The Elkay EZH2O® Bottle Filling Station delivers a clean quick water bottle fill and enhances sustainability by minimizing our dependency on disposable plastic bottles. Complete water station including single fountain with integral bottle filler. Sanitary no-touch sensor activation with automatic 20-second shut-off timer.

Features

  • Touchless, sensor activation (bottle filler) designed for easy use; easy-to-operate push-button activation (bubbler)
  • Fill rate is 1.5 GPM
  • Visual filter monitor with LED filter status indicator for when filter change is necessary
  • The 3,000-gallon filter is certified to NSF 42 and 53 for lead, Class 1 particulate, chlorine, taste and odor reduction
  • Green Ticker™ informs user of number of 20 oz. plastic water bottles saved from waste
  • Key plastic components are manufactured with silver ion antimicrobial agent helping to provide clean, stain- and odor-free surfaces
  • Silver ion antimicrobial protection on key plastic components to inhibit the growth of mold and mildew
  • Real drain system eliminates standing water
  • Touchless, sensor-activated bottle filler designed for easy use; easy-to-operate push-bar-activated bubbler


See More


Specifications

Specifications
Material

Stainless Steel

Number of Stations

1

Installation Type

Wall mount

Features

Antimicrobial
Filtered
Green Ticker™
Hands Free
Laminar Flow
Real Drain
Visual Filter Monitor

Power

115V/60Hz

Dimensions

L: 19-3/4"
W: 19"
H: 34-5/8"

Bubbler Style

Flexi-Guard ® Safety Bubbler

Mounting Type

Wall Mount (In-Wall Frame/Plate)

Chilling Capacity

Non-refrigerated

Installation Location

Indoor

Shipping Dimensions

L: 41-5/8"
W: 45-1/4"
H: 39-7/8"

Shipping Weight

121 LBS

Included With Product

Fountain with Integral Bottle Filling Station (EDFPBM114WS-F)
Mounting Frame (MFWSF100)
Filter

Ships In Multiple Boxes

Yes

ADA

Yes

Filtered

Yes

Code Compliance

ASME A112.19.3/CSA B45.4
CSA B45.4
CSA C22.2 No. 120
NSF 42
NSF 53
NSF 401
UL 399
NSF 61
NSF 372

Note

Refrigerated options available. If rear access is not available front access panels may be required such as ACCESS12X38-5 or AP99.
