Overview


UC - 600

The corrugated panel system is mechanically attached with exposed fasteners and installed in a non-sequential pattern. All systems are to be formed to specified dimensions and tolerances and should be accurately formed.

FEATURES

  • 0.491” deep corrugate profile
  • 20-year warranty on coil-coated Kynar 500®/Hylar 5000®
  • Excellent deflection resistance
  • Exposed fasteners
  • Non-sequential installation
  • Overlapping joint design (42″ width)
  • Very lightweight

MATERIAL OPTIONS

  • Coil-coated aluminum (20-year warranty)
  • Copper in various gauges and finishes
  • Post-painted aluminum (short run, custom colors)
  • Steel coil-coated (20-year warranty) extra smooth galvanized

FINISH OPTIONS

  • Batch anodized
  • Custom coatings
  • Fluoropolymer high gloss finish
  • Kynar 500®/Hylar 5000® high performance fluorocarbon resinous coatings

ADDITIONAL INFORMATION

  • Maximum length cannot exceed 50′
  • Oil canning is not a cause for rejection
  • Panels cannot be radiused
  • Panels cannot be tapered
