HD300 Wedge Barricade - K Rated Barrier

Certification Level: M50 P1 Crash Rated Barrier
Certified by: ASTM
Model #: HD300
Installation Design: Shallow Foundation Barrier

In its M50 crash test, the HD300 completely disabled the test vehicle, causing severe damage to the occupant department and power train. The maximum penetration recorded was an outstanding -1.8 m on the passenger’s side. The P1 penetration rating was given because the penetration beyond the protected side of the barrier was less than 1.0 m at the lower leading edge of the test vehicle’s cargo bed.

“The HD300 provides many of the flexibilities that security professionals want in a vehicle access barrier,” explains Greg Hamm, Delta Scientific vice president, marketing and sales. “Besides being easy to install and providing a fast emergency fast operation, low maintenance and multiple hit capabilities, customers can select either our new all electric control unit or Delta’s lauded hydraulic control unit.”

With its 24-inch (61 cm) shallow foundation and aesthetic design, the HD300 obviates the concerns of interference with buried pipes, power lines and fiber optic communication lines. The shallow foundation also reduces installation complexity, time, materials and corresponding costs. The HD300 is perfect for high water table locations and areas with corrosive soils. It provides low maintenance as all components are accessible from the sides or top of the barrier.

For increased security, the HD300 leverages Delta’s propriety counter-balanced technology to provide a 1.5 second emergency fast operation (EFO), responding to attacks very quickly. The electric actuator provides IP67 protection, meaning that the unit is totally protected against dust and as well as the effect of immersion between 15 cm and 1 m.
