Cube Care Company -GOLD Standard IV System

DOWNLOADS

IV Track - 1100IV

Durable

Heavy-gauge anodized aluminum: 1-7/16″w x 15/16″h.

Finished

Available in satin anodized or white powder coat finish.

Bend

Standard bend: 12″ radius


Category: I.V. holders | I.V. stands | health care equipment...

MasterFormat: Healthcare Equipment | Patient Care Equipment


View Product Details From Manufacturer


Cube Care Company
6043 N.W. 167th Street
Suite A-23
Miami Lakes, FL 33015
Tel: (305) 556-8700
Fax: (305) 556-8787

wecare@cubecare.com

https://www.cubecare.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


GOLD Standard IV System

IV Track - 1100IV

Durable

Heavy-gauge anodized aluminum: 1-7/16″w x 15/16″h.

Finished

Available in satin anodized or white powder coat finish.

Bend

Standard bend: 12″ radius

Carrier

Designed to receive our NC100 Non-Conductive Carrier.

Availability

Available with 28″, 39″, 45″, 51″, 57″ and 63″ drop.

Telescoping

Cube Care makes the highest quality IV Bottle Holders available.

Features Include:
  • Single button adjustment with auto lock for one-handed adjustment
  • Static reducing nylon inserts in hanging eyelets
  • All aluminum and stainless steel machined parts
  • Telescoping models offer up to 16″ of smooth, vertical adjustment
  • Bottle holder length is based on ceiling height
  • Standard sizes accommodate ceilings up to 10′. Extensions for taller ceilings are available

IV Track Carrier

NC 100 Carrier

Use with our 1100IV and 1100CT Track

Features:
  • Self-lubricating and maintenance-free
  • Glides smoothly around 12″ radius
  • Locks in place with single 180-degree twist
  • Non-conductive
  • All nylon wheels

IV Hook

WM110
Features:
  • Wall mount
  • Used as temporary I.V. bag/bottle holder in patient bathrooms
  • Available in lengths from 3-9 inches
  • Stainless steel hook with aluminum tube and flange


See More


Specifications

Typical Layouts
Colors

Cube Care IV Track - 1100IV

A heavy gauge extruded aluminum (1-7/16″w x 15/16″h) and available in satin anodized or white powder coat finish. Our IV track has standard 12″ radius corners and is designed to fit hospital room layouts. Typical layouts are oval, straight, or U-shaped. Designed to receive our NC100 Non-Conductive Carrier.

Cube Care Connector 1108
Aluminum connector is used to join two pieces of track. It is secured with four (4) rivets, two per track piece. For use with Cube Care IV Track - 1100IV.

Cube Care End Cap 1107
Aluminum End caps create a finished end for Cube Care IV Track. It is also used as a permanent stop for
curtain carriers. It is secured to the track with two (2) screws.

Cube Care NC100 Non-Conductive Carrier
Use with our 1100IV track. Self-lubricating and maintenance-free. All nylon wheels. Locks in place with single 180-degree twist.

Cube Care IV Hook - WM110
Wall mount, Used as temporary I.V. bag/bottle holder in patient bathrooms, Stainless steel hook with aluminum tube and flange.

IV Bottle Holder - 4000BH80

4 hook bottle holder for 8’0″ CH

IV Bottle Holder - 4000BH86
4 hook bottle holder for 8’6″ CH
IV Bottle Holder - 4000BH90
4 hook bottle holder for 9’0″ CH
IV Bottle Holder - 4000BH96
4 hook bottle holder for 9’6″ CH
IV Bottle Holder - 4000BH100
4 hook bottle holder for 10’0″ CH
IV Bottle Holder - 8000BH80
8 hook bottle holder for 8’0″ CH. Four IV stations at the top and bottom.
IV Bottle Holder - 8000BH86
8 hook bottle holder for 8’6″ CH. Four IV stations at the top and bottom.
IV Bottle Holder - 8000BH90
8 hook bottle holder for 9’0″ CH. Four IV stations at the top and bottom.
IV Bottle Holder - 8000BH96
8 hook bottle holder for 9’6″ CH. Four IV stations at the top and bottom.
IV Bottle Holder - 8000BH100
8 hook bottle holder for 10’0″ CH. Four IV stations at the top and bottom.
