Energy Series Polystyrene Insulated Steel Sectional Door

Our Energy Series doors help reduce heating and cooling costs. This door is ideal for warehouses, loading docks, industrial and agricultural facilities.

Clopay Energy Series overhead sectional doors provide durability, energy efficiency and multiple performance and design options. They feature polystyrene insulation which helps reduce heating and cooling costs with years of reliable service. These commercial doors offer stucco or woodgrain embossed steel exterior skins with flush, minor ribbed, or raised panel section designs. Ideal applications include warehouses, loading docks and industrial and agricultural facilities.

Springs and Hardware

Commercial doors are designed with hardware to meet demanding applications of commercial building usage. All commercial doors are provided with the following hardware as standard. For additional upgraded hardware see “Options” tab.

• 14 gauge hinges
• Commercial 10 ball steel rollers with options for nylon tire rollers
• 10,000 cycle torsion springs
• Steel step plate and lift handle for easy operation
• Inside slide lock for increase security
• 19 gauge steel hinge support plates
• 18-gauge single end stiles; 16-gauge double end stiles
• Galvanized aircraft cables with 7:1 safety factory
• 2” or 3” track in a variety of configurations to meet building design requirements


In commercial settings, space utilization and space constraints are important factors in choosing the correct hardware configuration for your application. Clopay track offerings and options enable you to make the most efficient use of available space. Options include standard lift, low head room front or rear mount, follow the roof pitch, full vertical or combination of these options.

Designed to counterbalance even the largest doors, commercial torsion spring assemblies can be designed for Industry standard 10,000 cycles or can be upgraded to 25,000, 50,000 or 100,000 expected life cycles.
