CM-7436 Series: 4.5" Wide Models CM-7536 Series: 6" Wide Models COLUMN™ Push Plate Switches
CM-74 & CM-75 Series Column™ switches offer greater user convenience and lower installation costs by providing a single activation device in place of two high/low switches, as required by a growing number of building codes across North America. These Column™ switches feature solid aluminum or stainless steel construction and are available in a range of finishes.
Also available is the option for Kinetic by Camden™ no-battery wireless or Lazerpoint™ battery powered wireless transmitters. The VR Series Column™ switches with hands-free sensors use active infra-red technology to eliminate the spread of germs.
- Kinetic™ no-battery wireless now available on CM-7536 series Column™ switches. Not available on 9" tall models.
- DPDT switch option not available. Use Camden CX-IRB relay if required.
FEATURES
- Low profile contoured design with easy activation from side angles
- Meets or exceeds California building code, section 1117B.6 requirements
- (2) Fully redundant SPDT, 15 Amp. UL listed switches
- Lazerpoint™ wireless compatible with provision for 'snap-in' battery powered transmitter
- Adjustable leveling screws for easy installation on uneven walls
- No internal wires exposed to moving parts
- 3 year warranty
No Battery Wireless Switches with Transmitter
- Built-in Kinetic(tm) no-battery wireless transmitter
- 300ft (open air) wireless range
- 500,000 cycles
Wired Manual Switches with Hands-Free Sensor
- Red/green light ring with switch or remote activation
- Adjustable sensor range 2" to 8" (5cm to 20cm)
- Adjustable sensor time delay (0.5 sec. to 20 sec.)
- Weather/water resistant sensor, IP65 rated
