CM-25, CM-26CB & CM-35 Series Narrow Push Plate Switches

CM-25, CM-26CB, CM-35 and CM-35N Series all-active switches are heavy-duty, ADA-compliant door controls. CM-25 (1-5/8" x 4-1/2") and CM-26CB/CM-35 series (2" x 4-1/2") rectangular faceplates are stainless steel, aluminum or solid brass. The CM-25 is designed to mount directly on a metal door frame or narrow surface box. The CM-35 and CM-35N Series meets new OBC requirements for activation plate size and is designed for mounting on a single gang box.

Note: CM-35 and CM-25 Series push plate switches are not available with optional DPDT contact.

Architectural Finishes:
CM-25 Series switches with architectural finish
only available with /1, /2, /3, /4 graphic options

CM-35 Series switches with architectural finish
only available with /2, /4, /8 graphic options

CM-26CB Series switches are only available
with /A2, /A4 graphics, in white

FEATURES

Durable stainless steel construction
All-Active design requires minimal actuation force
ADA compliant
Ultra quiet operation
Permanent debossed or laser engraved graphics
3 year warranty
CM-25, CM-26CB: Narrow switch with 1-3/4” wide activation plate mounts in aluminum jamb or in surface boxes
CM-35: 1 gang switch with narrow 2" wide activation plate, OBC-compliant
CM-35N: Narrow switch with 2" wide activation plate, OBC-compliant

See More

See Less

Specifications

SPECIFICATIONS

Contact Type:	N/O SPST
Switch Type:	Momentary
Contact Rating:	3 A @ 30 VDC
Temp Range:	-40°F to 140°F (-40°C to +60°C)
Std. Finish:	US32 / C32D
Dimensions:
CM-25, CM-26CB:	4-3/16" x 1-3/4" x 1-3/16" (113mm x 44mm x 30mm)
CM-35:	4-1/2"x 2-3/4" x 1-3/16" (114mm x 70mm x 30mm)

MODELS

Narrow Jamb
	CM-25	Narrow push plate switch, vertical mounting 4-1/2" x 1-3/4" (114mm x 44mm) Dimensions: 3.50"L x 6.00"W x 2.25"H Weight: 0.36lbs. Country of Origin:Canada
	CM-25H	1-3/4" x 4-1/2" (44mm x 114mm) Narrow push plate switch, horizontal mounting. /2 Wheelchair graphic, blue. All other graphic options black only. Dimensions: 0.36"L x 3.50"W x 6.00"H Weight: 2.25lbs. Country of Origin:Canada
Narrow Blue Jamb
	CM-26CB	Narrow Blue Push Plate Switch, White Graphics, Exposed Screws. 4-1/2" x 1-3/4" (114mm x 44mm) Graphic Options: '/2' (Wheelchair), '/4' (Wheelchair and Push to Open), & '/A4' (Active Wheelchair and Push to Open) only. No optional finishes. Dimensions: 3.5"L x 6.0"W x 2.25"H Weight: 0.36lbs. Country of Origin:Canada
Narrow, OBC Compliant
	CM-35	4-1/2" x 2" (114mm x 50.8mm) Single gang push plate switch, vertical mounting Dimensions: 3.50"L x 6.00"W x 2.25"H Weight: 0.36lbs. Country of Origin:Canada
	CM-35N	4-1/2" x 2" (114mm x 50.8mm) single gang faceplate with jamb mount back plate Dimensions: 3.5"L x 6.0"W x 2.5"H Weight: 0.36lbs. Country of Origin:Canada
Narrow (jamb), Kinetic(tm) No Battery Wireless
	CM-25HK	1-3/4” Width, Narrow push plate switch, horizontal mounting, brush stainless steel finish Dimensions: "L x "W x "H Weight: lbs. Country of Origin:Canada
	CM-25K	1-3/4” Width, Narrow push plate switch, vertical mounting, brush stainless steel finish Dimensions: 3.5"L x 6.0"W x 2.25"H Weight: 0.36lbs. Country of Origin:Canada
	CM-26CBK	1-3/4” Width, Narrow push plate switch, blue with white graphics, exposed screws. Graphic Options: ‘/2’, ‘/4’, ‘/A4’ only. No optional finishes. Dimensions: "L x "W x "H Weight: lbs. Country of Origin:Canada
	CM-35K	2” Width Narrow push plate switch, single gang back plate brushed stainless steel finish Dimensions: 5"L x 4"W x 3"H Weight: 0.85lbs. Country of Origin:Canada
	CM-35NK	2” Width Narrow push plate switch, vertical mounting,brushed stainless steel finish Dimensions: 3.5"L x 6"W x 2.5"H Weight: .36lbs. Country of Origin:Canada

OPTIONS & FINISHES

Faceplate Graphic Options
	CM-xxx/1	'BLANK' faceplate Add /1 to model #
	CM-xxx/2	'WHEELCHAIR' symbol, blue graphic Add /2 to model #
	CM-xxx/A2	'ACTIVE WHEELCHAIR' symbol, blue
	CM-xxx/2AL	WHEELCHAIR symbol with ARROW left, blue graphics Add /2AL to model #
	CM-xxx/2AR	WHEELCHAIR symbol with ARROW right, blue graphics Add /2AR to model #
	CM-xxx/3	'PUSH TO OPEN', black graphics Add /3 to model #
	CM-xxx/3F	'POUSSEZ POUR OUVRIR', black graphics Add /3F to model #
	CM-xxx/4	'WHEELCHAIR' symbol and 'PUSH TO OPEN', blue Add /4 to model #
	CM-xxx/4AL	WHEELCHAIR symbol with ARROW left, blue graphics Add /4AL to model #
	CM-xxx/4AR	WHEELCHAIR symbol with ARROW right, blue graphics Add /4AR to model #
	CM-xxx/A4	'ACTIVE WHEELCHAIR' symbol and 'Push to Open' text, blue
	CM-xxx/4F	'WHEELCHAIR' and 'POUSSEZ POUR OUVRIR' CM-25 blue graphics, CM-35 Black Graphics, Add /4F to model #
	CM-xxx/8	'PUSH TO LOCK', black text Add /8 to model #
	CM-xxx/8B	'LOCK SYMBOL' and 'PUSH TO LOCK', red graphic Add /8B to model #
Architectural Finishes (CM-25 Series: /1, /2, /3, /4 and CM-35 Series: /2, /4, /8)
	CM-xxx-SB	Add 'SB' to product # for satin brass finish (US4 / 606).
	CM-xxx-OB	Add 'OB' to product # for oil rub bronze finish (US10B / 613)
	CM-xxx-PB	Add 'PB' to product # for polished brass (US3 / 605)
	CM-xxx-AB	Add 'AB' to product # for antique brass finish (US5 / 609)
Weatherproof Options
	CM-xxx-WT	boot and water tight coating

COMPATIBLE MOUNTING BOXES

Mounting Boxes & Accessories: Narrow/Jamb
	CM-23	Surface Box, Standard Depth Flame and Impact resistant black polymer (ABS) 1-3/4"W x 4-5/8"H x 1-1/4"D
	CM-23D	Surface Box, Deep - For wireless. Flame and Impact resistant black polymer (ABS) 1-3/4"W x 4-5/8"H X 1-1/2"D. Not compatible with SureWave(tm) wireless no-touch switches (including CM-331/332 with plug-in CM-TX99 module or CM-336).
Mounting Boxes & Accessories: Single Gang
	CM-34BL	Surface Box, Standard Depth. Double wall flame/impact resistant black ABS, 2-3/4"W x 4-1/2"H x 1-3/4"D
	CM-34AL	Surface Box, Standard Depth, threaded conduit entry. Heavy duty cast aluminum 2-3/4"W x 4-1/2"H x 1-3/4"D
	CM-34D	Surface Box, Extra Deep - For wireless. Heavy duty grey polymer 2-3/4"W x 4-1/2"H x 3"D
	CM-120G	Rubber gasket for any stainless steel single gang faceplate
