| Model No. | Flanged | Body Width | Body Height | Accommodate Pipe | Coating | Weight | |
| 1) BPGWM236-Y | Standard Flange for flat wall | 5" | 36" | 2" | Powder Coated Yellow | 28 lbs. | |
| 2) BPGWM236-45-Y | 45 Degree Flange for corner | 5" | 36" | 2" | Powder Coated Yellow | 38 lbs. | |
| 3) BPGWM336-Y | Standard Flange for flat wall | 7" | 36" | 3" | Powder Coated Yellow | 36 lbs. | |
| 4) BPGWM336-45-Y | 45 Degree Flange for corner | 7" | 36" | 3" | Powder Coated Yellow | 50 lbs | |
| 5) BPGWM436-Y | Standard Flange for flat wall | 8" | 36" | 4" | Powder Coated Yellow | 42 lbs. | |
| 6) BPGWM436-45-Y | 45 Degree Flange for corner | 8" | 36" | 4" | Powder Coated Yellow | 58 lbs. | |
| 7) BPGWM636-Y | Standard Flange for flat wall | 11" | 36" | 6" | Powder Coated Yellow | 56 lbs. | |
| 8) BPGWM636-45-Y | 45 Degree Flange for corner | 11" | 36" | 6" | Powder Coated Yellow | 77 lbs. | |
| 9) BPGWM836-Y | Standard Flange for flat wall | 13" | 36" | 8" | Powder Coated Yellow | 66 lbs. | |
| 10) BPGWM836-45-Y | 45 Degree Flange for corner | 13" | 36" | 8" | Powder Coated Yellow | 92 lbs. | |
| 11) BPGWM1036-Y | Standard Flange for flat wall | 15" | 36" | 10" | Powder Coated Yellow | 77 lbs. | |
| 12) BPGWM1036-45-Y | 45 Degree Flange for corner | 15" | 36" | 10" | Powder Coated Yellow | 106 lbs. | |
| 13) BPGWM1236-Y | Standard Flange for flat wall | 17" | 36" | 12" | Powder Coated Yellow | 87 lbs. | |
| 14) BPGWM1236-45-Y | 45 Degree Flange for corner | 17" | 36" | 12" | Powder Coated Yellow | 120 lbs. | |
| 15) BPGWM246-Y | Standard Flange for flat wall | 5" | 46" | 2" | Powder Coated Yellow | 35 lbs. | |
| 16) BPGWM246-45-Y | 45 Degree Flange for corner | 5" | 46" | 2" | Powder Coated Yellow | 48 lbs. | |
| 17) BPGWM346-Y | Standard Flange for flat wall | 7" | 46" | 3" | Powder Coated Yellow | 47 lbs. | |
| 18) BPGWM346-45-Y | 45 Degree Flange for corner | 7" | 46" | 3" | Powder Coated Yellow | 64 lbs. | |
| 19) BPGWM446-Y | Standard Flange for flat wall | 8" | 46" | 4" | Powder Coated Yellow | 53 lbs. | |
| 20) BPGWM446-45-Y | 45 Degree Flange for corner | 8" | 46" | 4" | Powder Coated Yellow | 73 lbs. | |
| 21) BPGWM646-Y | Standard Flange for flat wall | 11" | 46" | 6" | Powder Coated Yellow | 71 lbs. | |
| 22) BPGWM646-45-Y | 45 Degree Flange for corner | 11" | 46" | 6" | Powder Coated Yellow | 99 lbs. | |
| 23) BPGWM846-Y | Standard Flange for flat wall | 13" | 46" | 8" | Powder Coated Yellow | 85 lbs. | |
| 24) BPGWM846-45-Y | 45 Degree Flange for corner | 13" | 46" | 8" | Powder Coated Yellow | 117 lbs. | |
| 25) BPGWM1046-Y | Standard Flange for flat wall | 15" | 46" | 10" | Powder Coated Yellow | 98 lbs. | |
| 26) BPGWM1046-45-Y | 45 Degree Flange for corner | 15" | 46" | 10" | Powder Coated Yellow | 135 lbs | |
| 27) BPGWM1246-Y | Standard Flange for flat wall | 17" | 46" | 12" | Powder Coated Yellow | 112 lbs. | |
| 28) BPGWM1246-45-Y | 45 Degree Flange for corner | 17" | 46" | 12" | Powder Coated Yellow | 154 lbs. | |
| Model No. | Flanged | Body Width | Body Height | Accommodate Pipe | Coating | Weight | Minimum Order Quantity |
| 29) BPGWM236-G | Standard Flange for flat wall | 5" | 36" | 2" | Hot Dip Galvanized | 30 lbs. | 17 |
| 30) BPGWM236-45-G | 45 Degree Flange for corner | 5" | 36" | 2" | Hot Dip Galvanized | 41 lbs. | 13 |
| 31) BPGWM336-G | Standard Flange for flat wall | 7" | 36" | 3" | Hot Dip Galvanized | 39 lbs. | 13 |
| 32) BPGWM336-45-G | 45 Degree Flange for corner | 7" | 36" | 3" | Hot Dip Galvanized | 54 lbs. | 10 |
| 33) BPGWM436-G | Standard Flange for flat wall | 8" | 36" | 4" | Hot Dip Galvanized | 45 lbs | 12 |
| 34) BPGWM436-45-G | 45 Degree Flange for corner | 8" | 36" | 4" | Hot Dip Galvanized | 62 lbs. | 9 |
| 35) BPGWM636-G | Standard Flange for flat wall | 11" | 36" | 6" | Hot Dip Galvanized | 60 lbs. | 9 |
| 36) BPGWM636-45-G | 45 Degree Flange for corner | 11" | 36" | 6" | Hot Dip Galvanized | 82 lbs. | 7 |
| 37) BPGWM836-G | Standard Flange for flat wall | 13" | 36" | 8" | Hot Dip Galvanized | 71 lbs. | 8 |
| 38) BPGWM836-45-G | 45 Degree Flange for corner | 13" | 36" | 8" | Hot Dip Galvanized | 98 lbs. | 6 |
| 39) BPGWM1036-G | Standard Flange for flat wall | 15" | 36" | 10" | Hot Dip Galvanized | 82 lbs. | 7 |
| 40) BPGWM1036-45-G | 45 Degree Flange for corner | 15" | 36" | 10" | Hot Dip Galvanized | 113 lbs | 5 |
| 41) BPGWM1236-G | Standard Flange for flat wall | 17" | 36" | 12" | Hot Dip Galvanized | 96 lbs. | 6 |
| 42) BPGWM1236-45-G | 45 Degree Flange for corner | 17" | 36" | 12" | Hot Dip Galvanized | 128 lbs. | 4 |
| 43) BPGWM246-G | Standard Flange for flat wall | 5" | 46" | 2" | Hot Dip Galvanized | 38 lbs. | 14 |
| 44) BPGWM246-45-G | 45 Degree Flange for corner | 5" | 46" | 2" | Hot Dip Galvanized | 52 lbs. | 10 |
| 45) BPGWM346-G | Standard Flange for flat wall | 7" | 46" | 3" | Hot Dip Galvanized | 50 lbs. | 10 |
| 46) BPGWM346-45-G | 45 Degree Flange for corner | 7" | 46" | 3" | Hot Dip Galvanized | 69 lbs. | 8 |
| 47) BPGWM446-G | Standard Flange for flat wall | 8" | 46" | 4" | Hot Dip Galvanized | 57 lbs. | 9 |
| 48) BPGWM446-45-G | 45 Degree Flange for corner | 8" | 46" | 4" | Hot Dip Galvanized | 78 lbs. | 7 |
| 49) BPGWM646-G | Standard Flange for flat wall | 11" | 46" | 6" | Hot Dip Galvanized | 76 lbs. | 7 |
| 50) BPGWM646-45-G | 45 Degree Flange for corner | 11" | 46" | 6" | Hot Dip Galvanized | 106 lbs. | 5 |
| 51) BPGWM846-G | Standard Flange for flat wall | 13" | 46" | 8" | Hot Dip Galvanized | 91 lbs. | 6 |
| 52) BPGWM846-45-G | 45 Degree Flange for corner | 13" | 46" | 8" | Hot Dip Galvanized | 125 lbs. | 4 |
| 53) BPGWM1046-G | Standard Flange for flat wall | 15" | 46" | 10" | Hot Dip Galvanized | 105 lbs. | 5 |
| 54) BPGWM1046-45-G | 45 Degree Flange for corner | 15" | 46" | 10" | Hot Dip Galvanized | 144 lbs. | 4 |
| 55) BPGWM1246-G | Standard Flange for flat wall | 17" | 46" | 12" | Hot Dip Galvanized | 120 lbs. | 5 |
| 56) BPGWM1246-45-G | 45 Degree Flange for corner | 17" | 46" | 12" | Hot Dip Galvanized | 164 lbs. | 4 |
