Armstrong World Industries, Inc. -ULTIMA Health Zone AirAssure: 1959

DOWNLOADS
  • Factory-gasketed edges reduce air leakage through the ceiling plane to direct airflow more effectively and improve indoor air quality
  • Get total noise control and floor plan versatility with TOTAL ACOUSTICS ceiling panels: NRC + CAC = TOTAL ACOUSTICS Performance

Category: clean room ceilings | commercial ceilings | mineral fiber ceilings...

MasterFormat: Ceilings | Acoustical Panel Ceilings | Acoustical Tile Ceilings...



Armstrong World Industries, Inc.
P.O. Box 3001
Lancaster, PA 17604
Tel: (717) 397-0611

techline@armstrongceilings.com

https://www.armstrongceilings.com

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


ULTIMA Health Zone AirAssure: 1959

  • Factory-gasketed edges reduce air leakage through the ceiling plane to direct airflow more effectively and improve indoor air quality
  • Get total noise control and floor plan versatility with TOTAL ACOUSTICS ceiling panels: NRC + CAC = TOTAL ACOUSTICS Performance
  • Anti-Bacterial/Mold/Mildew - BIOBLOCK Plus performance resists the growth of odor and stain-producing bacteria as well as mold and mildew on the ceiling tile surface
  • Improved sound blocking performance - provides some of the highest speech privacy in the TOTAL ACOUSTICS portfolio with a CAC 40.
  • Clean + Simple - AIRASSURE panels are part of the SUSTAIN portfolio and are free of Red List Chemicals for better indoor air quality
  • Clean Room Performance up to ISO Class 5 (Class 100) using standard non-gasketed suspension systems
  • Exceptional durability & cleanability impact-, scratch-, and soil-resistant
  • CLEANASSURE - safe for use with disinfectant cleaners
  • Long-lasting water-repellency; washable and scrubbable
  • AIRASSURE ceilings enable easy conversion to negative or positive pressure-controlled spaces (without hold-down clips)
  • Energy-saving, high light-reflective finish
  • 30-Year Limited System Warranty against visible sag, mold, and mildew


See More


Specifications

EdgeDimensionsAcoustics
0.70 NRC 40 CAC
Square Lay-In 15/16"24" x 48" x 3/4"
Performance

Acoustics

Sound Absorption (NRC)

0.70

Sound Blocking (CAC)

40
Fire
Fire Performance Class A

Light Reflectance

86%

Sag/Humidity Resistance

HumiGuard Plus
Clean Room Classification Clean Room Class 100
Insulation Value R Factor-BTU: 2.20 BTU
R Factor-Watts: 0.39 m2 K/W

BioBlock

Yes
Disinfectability

Fog

Spray

Wipe

Durability

Water Repellent

Soil Resistance

Impact Resistance

Scratch Resistance

Washability

Scrubbability

Special Applications
  • Clean Room
Physical Data
Material Mineral Fiber
Texture Smooth
Surface Finish Acoustically transparent membrane with factory applied latex paint
Shape Rectangle
Weight 1.08 PF2
Sq Ft (Sq Ft / Carton) 48
Pieces / Carton 6
ASTM Classification Type: IV, Form: 2, Pattern: E
Installation Method Grid (Suspended)
Accessibility
Accessibility Yes
