Armstrong World Industries, Inc. -TECTUM DesignArt - Shapes Direct - Attach Ceilings: 5420P04T10

DOWNLOADS

  • 30 standard Shapes direct-attach ceiling panels available in 24 new standard colors, and natural
  • Products in the TECTUM DesignArt portfolio are made to work together
  • Available for ceiling and wall applications


Category: acoustical ceilings | direct mount ceilings | fire-resistant ceilings...

MasterFormat: Ceilings | Acoustical Ceilings | Acoustical Panel Ceilings...



Armstrong World Industries, Inc.
P.O. Box 3001
Lancaster, PA 17604
Tel: (717) 397-0611

techline@armstrongceilings.com

https://www.armstrongceilings.com

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


TECTUM DesignArt - Shapes Direct - Attach Ceilings: 5420P04T10

  • 30 standard Shapes direct-attach ceiling panels available in 24 new standard colors, and natural
  • Products in the TECTUM DesignArt portfolio are made to work together
  • Available for ceiling and wall applications
  • TECTUM DesignArt - Shapes panels have UL® Certified acoustics with testing and reporting that align with industry-wide best practices
  • Great retrofit solution for noise reduction
  • Excellent sound absorption - NRC up to 0.85 (1" panel, C-40 Mounting)
  • CLEANASSURE family of products - includes disinfectable panels, suspension systems, and trim (standard colors only)
  • Sustainable Beyond Standard: Custom sizes in 1" thickness and all standard panels are part of the SUSTAIN portfolio and meet the most stringent industry sustainability compliance standards today
  • All edges are beveled and painted
  • Touch-up paint for standard colors available
  • Panels can be mechanically fastened to a wide variety of surfaces including masonry, drywall, drywall grid system, wood, and more
  • USDA Biobased content: 98%


See More


Specifications

EdgeDimensionsAcoustics
0.4 NRC A 0.45 NRC D-20 0.8 NRC C-20 0.85 NRC C-40
Beveled (long side) / Beveled (short side)24" x 48" x 1"
Performance

Acoustics

NRC Rating A Mounting 0.4
NRC Rating D-20 Mounting 0.45
NRC Rating C-20 Mounting 0.8
NRC Rating C-40 Mounting 0.85
Fire
Fire Performance Class A

Sag/Humidity Resistance

Standard
Disinfectability

Fog

Durability

Impact Resistance

Scratch Resistance

Special Applications
  • Exposed Structure
Physical Data
Material TECTUM Wood Fiber
Texture Coarse
Shape Left Parallelogram
Weight 1.63 PF2
Sq Ft (Sq Ft / Carton) 0.25
Pieces / Carton 1
ASTM Classification Type: XIV, Form: 2,
Installation Method Direct attach
