Armstrong World Industries, Inc. -METALWORKS IMMIX Linear: 6374A61M15

DOWNLOADS

A panelized torsion spring metal ceiling system in a variety of linear configurations, achieving an accessible, smooth monolithic or open reveal linear look installed up to twice as fast as individual plank systems.


Category: acoustical ceiling suspension assemblies | commercial ceilings | dropped ceilings...

MasterFormat: Ceilings | Acoustical Panel Ceilings | Specialty Ceilings...


View Product Details From Manufacturer


Armstrong World Industries, Inc.
P.O. Box 3001
Lancaster, PA 17604
Tel: (717) 397-0611

techline@armstrongceilings.com

https://www.armstrongceilings.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


METALWORKS IMMIX Linear: 6374A61M15

A panelized torsion spring metal ceiling system in a variety of linear configurations, achieving an accessible, smooth monolithic or open reveal linear look installed up to twice as fast as individual plank systems.

  • Edge: Square 15/16"
  • Dimensions: 24" x 96"
  • Shape: Rectangle
  • Plank Height: 1"
  • Plank Width: 6"
  • Number of Planks: 4 planks
  • Space Between Planks: 1/8"
  • Perforation: M15
  • Acoustics:
    NRC: 0.75
  • Fire Performance: Class A
  • Light Reflectance: 75%
  • Face Profile: 15/16"


See More


Specifications

WhitelumeGun MetalSilverlume
Acoustics
Sound Absorption (NRC) 0.75
% Open Area 0%
Fire
Fire Performance Class A
Light Reflectance 75%
Mold/Mildew Resistance Inherent
Disinfectability
Fog
Spray
Wipe
Durability
Soil Resistance
Impact Resistance
Scratch Resistance
Washability
Scrubbability
Cape May CherryLa Jolla OakMontauk DriftwoodNew Haven Walnut
Material Metal
Surface Finish Factory-applied polyester paint
Shape Rectangle
Weight 0.73 lbs/SF
Sq Ft (Sq Ft / Piece) 16
Pieces / Carton 1
ASTM Classification Type: XX, Pattern: C
Installation Method Grid (Suspended)
Accessibility Yes
Contract Options
General Services Administration (GSA) Schedule General Services Administration (GSA) Schedule
Cooperative Educational Services (CES) Cooperative Educational Services (CES)
California Multiple Award Schedules (CMAS) California Multiple Award Schedules (CMAS)
Custom ColorCustom Wood Look Finish
