Armstrong World Industries, Inc. -METALWORKS 3D: 7220DN4M1

DOWNLOADS

3D ceiling system panels are available in five different heights that can be installed up or down.


Category: acoustical ceilings | commercial ceilings | impact resistant ceilings...

MasterFormat: Ceilings | Acoustical Panel Ceilings | Acoustical Tile Ceilings...



Armstrong World Industries, Inc.
P.O. Box 3001
Lancaster, PA 17604
Tel: (717) 397-0611

techline@armstrongceilings.com

https://www.armstrongceilings.com

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


METALWORKS 3D: 7220DN4M1

3D ceiling system panels are available in five different heights that can be installed up or down.

Performance
  • Define and accentuate spaces with unique 3D look
  • Reflections laminate finishes provide wood-look visual
  • Standard Tegular and 1", 2", 3", and 4" panel heights
  • Easy to install
  • Perforation option available for acoustics
  • Durable - Washable, Scrubbable, Soil-resistant


See More


Specifications

EdgeDimensionsPerforation
Square Down Tegular 9/16 in24 in x 24 in x 4 inM1 - Unperforated
Performance
Acoustics
% Open Area 0%
Fire
Fire Performance Class A (painted) / Class B (laminate)
Light Reflectance 77%
Sag/Humidity Resistance Standard
Durability Soil Resistance
Impact Resistance
Washability
Scrubbability
Accessibility
Accessibility Yes
Physical Data
Material Metal
Texture Smooth
Surface Finish Polyester paint, acrylic latex paint on acoustically transparent membrane, or vinyl-faced membrane
Shape Rectangle
Weight 1.0 PF2
Sq Ft (Sq Ft / Carton) 4
Pieces / Carton 1
ASTM Classification Type: XX, Pattern: G
Installation Method Grid (Suspended)
