Overview


INTERLUDE XL HRC Dimensional Tee: XL6180HRC

This dimensional 9/16" suspension system offers high-recycled content for improved LEED credits

Performance
  • Hot-dipped galvanized coating inhibits red rust better than electrogalvanized or painted systems
  • XL 2 staked-on end detail provides secure locked connection
  • Unmitered intersections for flexibility of cross tee placement
  • Accommodates virtually any fixture, especially 1' x 4' light fixtures and air handling
  • FASTSIZE main beams and cross tees can be ordered with special sizing and route spacing for your project needs in one carton minimums with two week lead times
  • Blizzard White powder-coated finish coordinates with OPTIMA, ULTIMA, CALLA, and LYRA ceiling panels for a clean, seamless, monolithic installed visual.


See More


Specifications

Component TypeDescriptionDimensions
Cross Tee96in Interlude XL CrossTee HRC96 in x 9/16 in x 1-3/4 in
Performance
Hanger Spacing 4' - 12.59 plf
Physical Data
Material Hot-dipped Galvanized Steel
Rout/Slot Spacing and UOM 12 in
Cross Tee/Main Beam Interface Flush fit and center protrusion
End Detail Staked-on clip (XL)
Feet (Ft / Carton) 160
Pieces / Carton 20
Visual
Length 96 in
Face Profile 9/16 in
Height 1-3/4 in
Profile Type Dimensional Tee
Component Type Cross Tee
