Armstrong World Industries, Inc. -GRAPHIS Rustex: 2602 - Acoustical Ceiling Tile

DOWNLOADS

These panels offer bold geometric and linear patterns with unique visual designs


Category: acoustical ceilings | commercial ceilings | drop-in ceiling panels...

MasterFormat: Ceilings | Acoustical Panel Ceilings | Acoustical Tile Ceilings...


View Product Details From Manufacturer


Armstrong World Industries, Inc.
P.O. Box 3001
Lancaster, PA 17604
Tel: (717) 397-0611

techline@armstrongceilings.com

https://www.armstrongceilings.com

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


GRAPHIS Rustex: 2602 - Acoustical Ceiling Tile

These panels offer bold geometric and linear patterns with unique visual designs

Performance
  • Finely sculptured geometric patterns
  • Single- and multi-design options
    • High light reflectance


See More


Specifications

EdgeDimensionsPatternAcoustics
Beveled Tegular 9/16 or 15/16 in24 in x 24 in x 3/4 inLinear Beveled0.55 NRC
30 CAC
Performance
Acoustics
Sound Absorption (NRC) 0.55
Sound Blocking (CAC) 30
Fire
Fire Performance Class A (UL)
Light Reflectance 75%
Sag/Humidity Resistance HumiGuard Plus
Insulation Value R Factor-BTU: 1.60 BTU
R Factor-Watts: 0.28 m2 K/W
BioBlock Yes
Physical Data
Material Mineral Fiber
Texture Fine
Surface Finish Factory applied latex paint
Shape Rectangle
Weight 0.90 PF2
Sq Ft (Sq Ft / Carton) 48
Pieces / Carton 12
ASTM Classification Type: III, Form: 2, Pattern: JZ
Installation Method Grid (Suspended)
