AlumiRamp -Armada Residential Modular Ramp System

DOWNLOADS

The ARMADA SYSTEM is a residential modular ramp which can easily be moved or reconfigured if you have to relocate. Made of anodized aluminum, it will remain good looking through years of use. This system complies with ANSI and ADA guidelines.

10 year warranty


Category: 107449 | access ramps | handicap ramps...

MasterFormat: Exterior Specialties | Manufactured Exterior Specialties | Modular Landing and Ramp Systems



AlumiRamp
855 E Chicago Rd
Quincy, MI 49082
Tel: (800) 800-3864
Fax: (517) 639-4314

sales@alumiramp.com

https://www.alumiramp.com/

Find a rep/distributor

Request More Info

DOWNLOADS

Related Products

Overview


Armada Residential Modular Ramp System

The ARMADA SYSTEM is a residential modular ramp which can easily be moved or reconfigured if you have to relocate. Made of anodized aluminum, it will remain good looking through years of use. This system complies with ANSI and ADA guidelines.

  • 10 year warranty
  • assembles easily with a 1/2" wrench
  • legs can be recessed under the system for a clean look
  • all anodized aluminum: handrails and ramp will not chip, flake, or rust
  • heavy duty welded aluminum construction
  • non-combustible
  • bidirectional knurled tread forms a rugged skid resistant surface that
    cannot wear off
  • fully adjustable height and slope
  • all stainless steel fasteners
  • universal platforms
  • no footings required
  • recyclable


See More


Specifications

MODEL

SIZE

TYPE

WEIGHT CAPACITY

APLA48X6048" W x 60" Lplatform100 psf
APLA60X6060" W x 60" Lplatform100 psf
APLA60X9660" W x 96" Lplatform100 psf
ARMP36X0436" W x 4' Lramp750 lbs.
ARMP36X0536" W x 5' Lramp750 lbs.
ARMP36X0636" W x 6' Lramp750 lbs.
ARMP36X0836" W x 8' Lramp750 lbs.
ARMP36X0236" W x 2' Lstarter ramp750 lbs.

Standard sizes shown. Custom sizes available on ramps, platforms and steps.
